Summary of Contents for Technica Engineering 1000BASE-T1 MediaConverter_EMC
- Page 1 1000BASE-T1 100BASE-T1 MEDIACONVERTER MEDIACONVERTER _EMC USER MANUAL September 2018 Manual-Version: 2.0 Hardware-Version: 1.4...
-
Page 2: Table Of Contents
CONTENT GENERAL INFORMATION ................... 3 Functionality and Features of the 1000BASE-T1 MediaConverter_EMC ..3 Warranty and Safety Information ................ 4 Declaration of conformity ..................5 HARDWARE INTERFACES ..................6 Connectors ......................6 2.1.1 MATEnet Connectors ..................6 2.1.2 Optical Interface on the backside ..............7 2.1.3... -
Page 3: General Information
1.1 Functionality and Features of the 1000BASE-T1 MediaConverter_EMC Figure 1—1: 1000BASE-T1 MediaConverter_EMC The Technica Engineering 1000BASE-T1 MediaConverter_EMC transmits data frames directly from the physical layer 1000BASE-T1 to a chosen physical layer of the used SFP module. This SFP modules can be standard Ethernet RJ45 modules or optical Gbit Ethernet SFP modules with constant delay. -
Page 4: Warranty And Safety Information
General Information: Power requirement: 8 to 16 Volt DC (nominal 12 Volt DC) Power consumption: 2 Watt Size: 95 x 100 x 27 mm Weight: 0,3 kg International Protection: IP 2 0 Operating temperature: -40° to +80 °Celsius LINKS: The User can download the latest firmware and documentation for the 1000BASE-T1 MediaConverter_EMC here: https://technica-engineering.de/produkt/1000base-t1-emc-converter/ 1.2 Warranty and Safety Information... -
Page 5: Declaration Of Conformity
1.3 Declaration of conformity Figure 1—2: Declaration of conformity 1000BASE-T1 MediaConverter EMC User Manual... -
Page 6: Hardware Interfaces
2.1 Connectors On the label on top of the device you can see an overview about all HW-Interfaces of the 1000BASE-T1 MediaConverter_EMC. Figure 2—1: Label of 1000BASE-T1 MediaConverter_EMC with pinning information 2.1.1 MATEnet Connectors The pinning of the ECU connector is shown on the label on top of the device as well. -
Page 7: Optical Interface On The Backside
Pinning: Function Minus Plus Figure 2—2: MATEnet Connector Table 2—1: Pinning MATEnet Connector 2.1.2 Optical Interface on the backside The optical interface is a serial terminal connection. For using this a special USB Adapter is required (Please ask for this adapter). •... -
Page 8: Sfp-Interface
Shown Information: Mainly there are SQI and Block Error Counter displayed. Here is an example: Figure 2—3: Example for shown values in Tera Term 2.1.3 SFP-Interface There is one SFP cage for a MiniGBIC module. Following SFP-modules are tested and recommended: Copper SFP-module: BEL SFP-1GBT-05, 10/100/1000BASE-T SFP Optical SFP-module:... -
Page 9: Other Interfaces
Chapter 3). 2.2.2 Status LEDs The 1000BASE-T1 MediaConverter_EMC has four LEDs at the frontside of the case. Upper left LED (No. 1): Green Color. It is lit when there is a linkup on the SFP-Port Lower left LED (No. 2): Yellow Color. -
Page 10: Configuration Of The Device
3 CONFIGURATION OF THE DEVICE The 1000BASE-T1 MediaConverter_EMC is configured by two DIP-Switches on the front of the device. DIP-Switch Status Description ON (up) 1000BASE-T1 Port is set to Master OFF (down) 1000BASE-T1 Port is set to Slave ON (up) -
Page 11: 1000Base-T1 Filter
4 1000BASE-T1 Filter The following 1000BASE-T1 Filter is used in the 1000BASE-T1 MediaConverter_EMC: The Pulse AE5002 is used. Figure 4—1: Used Filter in 1000BASE-T1 MediaConverter_EMC 1000BASE-T1 MediaConverter EMC User Manual... -
Page 12: General Emc Test Information
5 GENERAL EMC TEST INFORMATION Testcases: We test our EMC products with 350 V/m in a Stripline setup from 1 MHz to 1 GHz. The devices are not damaged in this setup. There will be no Link Drop on 100BASE-T1 or 1000BaseT1. Warning: At frequencies below 1 MHz immunity must be tested at a maximum of 100V/m. -
Page 13: Additional Information
6 ADDITIONAL INFORMATION • The 1000BASE-T1 MediaConverter_EMC is optimized for automotive use. The maximum cable length for 1000BASE-T1 segments is limited to 15 meters. • HW-version until v1.3 was delivered with nano-MQS connector instead of MATEnet connectors. If you need information about the pinning for the old version, please ask for that support@technica-engineering.de. -
Page 14: List Of Figures
Figure 1—1: 1000BASE-T1 MediaConverter_EMC ............3 Figure 1—2: Declaration of conformity ................5 Figure 2—1: Label of 1000BASE-T1 MediaConverter_EMC with pinning information .. 6 Figure 2—2: MATEnet Connector..................7 Figure 2—3: Example for shown values in Tera Term ............8 Figure 4—1: Used Filter in 1000BASE-T1 MediaConverter_EMC ........ -
Page 15: Changelog
8 CHANGELOG Version Chapter Description Date First release Rework of design and update of all information 19.11.2018 Table 8—1: Changelog 1000BASE-T1 MediaConverter EMC User Manual... -
Page 16: Contact
9 CONTACT If you have any questions regarding this product, please feel free to contact us: Technica Engineering GmbH Leopoldstr. 236 80807 München Germany Fax: +49-89-34290265 Info@technica-engineering.de www.technica-engineering.de 1000BASE-T1 MediaConverter EMC User Manual...
