TPR-WDMX-TCVR
DMX 512 Wireless Control System
Version: 1.4 27 JAN 2018
U S E R M a n U a l
This product manual contains important information about the safe installation and use
of this product. Please read and follow these instructions carefully and keep this manual
in a safe place for future reference.
Advertisement
Table of Contents
Summary of Contents for TPR WDMX-TCVR
- Page 1 TPR-WDMX-TCVR DMX 512 Wireless Control System Version: 1.4 27 JAN 2018 U S E R M a n U a l This product manual contains important information about the safe installation and use of this product. Please read and follow these instructions carefully and keep this manual...
- Page 2 DMX 512 Wireless Control User Manual COnTInUED 1. Introduction DMX wireless system is compatible with any DMX512 controller and fixture. Internal data transfer rate can reach 250K. Speedy transmission and autocorrect Interference feature. One-to-one or one transmitter to multiple receivers. Several transmitters can be installed at same location. Each unit is interchangeable as Transmitter or Receiver.
- Page 3 DMX 512 Wireless Control User Manual COnTInUED 3.3 Safety Instructions Please read these instructions carefully, which includes important information about the installation, usage and maintenance. • Please keep this user manual for further reference. • always make sure the unit is connected to proper voltage as rated on product and manual. •...
- Page 4 DMX 512 Wireless Control User Manual COnTInUED 4. Product Overview (Front Panel) ITEM DESCRIPTION FUNCTION lCD display Display operation data Change setting of lCD display menu DOWn Change setting of lCD display menu MODE Operation menu selection RX (red) acting as receiver. Red lED will keep flashing when receiving wireless signal.
- Page 5 DMX 512 Wireless Control User Manual COnTInUED 5. Product Overview (Rear Panel) ITEM DESCRIPTION FUNCTION DMX OUT DMX 512 signal output DMX In DMX 512 signal input Power InPUT aC 100 -240V 50 /60Hz SMa anTEnna SMa antenna input aIR InTERCHanGER Balances the pressure inside and outside of the box 6.
- Page 6 DMX 512 Wireless Control User Manual COnTInUED transmitter and Receiver must work at same frequency with same address code. 7. Display Instruction 8. How to Set Up 8.1 Antenna Installation: High as possible above barriers 8.2 Antenna Direction: transmitter antenna to face receiver antenna 8.3 Antenna Position: as far away from interference Ex: Wlan antenna and equipment with motor like moving heads etc.
- Page 7 DMX 512 Wireless Control User Manual COnTInUED 9. Frequency Select CHANNEL FREQUENCY (MHz) 2400 2401 2402 2403 2404 2405 2406 2407 2408 2409 2410 2411 2412 2413 2414 2415 • • • • • • • • • • • • • • 1 2 4 2 5 2 4...
- Page 8 DMX 512 Wireless Control User Manual COnTInUED...
