Bob Weir's Real Deal
User's Guide
All contents c Absara Audio LLC 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bob Weir’s Real Deal and is the answer not in the manual?

Questions and answers

Summary of Contents for pigtronix Bob Weir’s Real Deal

  • Page 1 Bob Weir’s Real Deal User’s Guide All contents c Absara Audio LLC 2018...

  • Page 2: Table Of Contents

    Single Source Mode ....Dual Source Mode (TRS) ....10 Dual Source Mode (External Mic with Phantom Power) 11 4 Pigtronix Limited Warranty...

  • Page 3: Welcome To The Real Deal

    Welcome to The Real Deal Thank you for entering the realm of Pigtronix. Bob Weir’s Real Deal pedal is an acoustic preamp. This pedal is capable of re-structuring the sonic characteristics of an acoustic guitar, producing a rich sound for any scenario.

  • Page 4: Safety Precautions

    Thank You The Real Deal represents a decade of continuous R&D involving some of the top minds in the audio industry. Pigtronix would like to formally thank the following individuals for their help in creating the Real Deal Acoustic Preamp:...

  • Page 5: Anatomy And Functions

    Jacks 1. DC 18V - Use only the 18-Volt, 300mA, negative tip power supply that came with your Pigtronix Real Deal. Using the wrong power supply is likely to result in a damaged pedal. 2. OUTPUT - Effect output. Plug in your amp, mixer, or DI box here.
  • Page 6 CHAPTER 2. ANATOMY AND FUNCTIONS mono inputs as well as TRS Dual Source inputs which carry sepa- rate audio signals on the TIP and RING with a shared Ground on the SLEEVE. The TIP of the INPUT jack goes to the PICKUP channel while the RING of the INPUT jack goes to the MICRO- PHONE channel.

  • Page 7: Knobs And Switches

    CHAPTER 2. ANATOMY AND FUNCTIONS Knobs and Switches...
  • Page 8 CHAPTER 2. ANATOMY AND FUNCTIONS 5. ENGAGE - This footswitch turns the filter section of the Real Deal on and off. When the engage light is turned off, the high and low pass filters are bypassed. In bypass, the preamp stages and summing stages remain active, allowing both the INPUT (TS / TRS) and EXT MIC inputs to be combined with no tonal coloration.
  • Page 9 CHAPTER 2. ANATOMY AND FUNCTIONS DUAL SOURCE mode is also intended for use with a stan- dard (TS) instrument cable feeding the INPUT jack along with a external MICROPHONE feeding the EXT MIC jack. Using DUAL SOURCE mode, it is also possible to combine both a TRS input carrying two audio sources with a third audio signal feeding the EXT MIC jack.

  • Page 10: Getting Started

    1. Unpack your Real Deal and place it on a flat, stable surface. 2. Make sure you are using the 18-Volt DC (negative center) power supply that came with your Pigtronix Real Deal. 3. Plug the power cord into the 18VDC jack on the back of the Real Deal and then plug the power adapter into an electrical socket.

  • Page 11: Dual Source Mode (Trs)

    CHAPTER 3. GETTING STARTED 2. Set the volume knob fully counter-clockwise. Turn the PICKUP and MICROPHONE knobs to noon. 3. Set the DUAL SOURCE switch to the UP position (SINGLE SOURCE). 4. Set the PHASE switch to the DOWN position (IN PHASE). 5.

  • Page 12: Dual Source Mode (External Mic With Phantom Power)

    CHAPTER 3. GETTING STARTED 4. Set the PHASE switch to the DOWN position (IN PHASE). 5. Set the PHANTOM switch to the UP position (OFF). 6. Turn up the VOLUME knob until you have a good volume on your amplifier. Press the foot switch to engage the filter. 7.
  • Page 13 CHAPTER 3. GETTING STARTED Note: The Real Deal provides 48VDC @ 20mA. Be sure the device you are attempting to power is designed for industry standard +48VDC 6. Set the PHASE switch to the DOWN position (IN PHASE). 7. Turn up the VOLUME knob until you have a good volume on your amplifier.

  • Page 14: Pigtronix Limited Warranty

    Pigtronix Limited Warranty Your Pigtronix effect pedal comes with a 1-year limited warranty on parts and workmanship. During the warranty period we will repair or replace, at our option, defective parts or pedals free of charge, and return them to the owner. Warranty service does not include damaged, modified, or misused pedals and such pedals will be subject...
