SSA RITS-N RC-200 User Manual

Digital
Door Key
User's Guide
Thank you so much for buying this RITS-N Digital Door Key. This Digital Door Key was designed to open automatically
a door in the manner of inputting an authorized password or approaching an authorized ID card to the door.
1

PARTS DESCRIPTION

2

INSTALLATION AND WIRING

3 3
OPERATION CHECK & CAUTION
1. Digital Door Key is 12V Power Supply only.
2. Once it has been connected to the power supply for the first time, the System LED turns on and
simultaneously the Number Indicator blinks once, followed by "beep" sound.
202-503, Bucheon Techno Park, 192, Yakdae-Dong, Wonmi-ku, Bucheon-Si,Kyunggido, Korea 202-503, Bucheon Techno Park, 192, Yakdae-Dong, Wonmi-ku, Bucheon-Si,Kyunggido, Korea
3. Any wrong wiring may cause a serious damage to the unit.
www.ssamotor.co.kr www.ssamotor.co.kr
(RC-200)
System LED
Error LED
TEL : 82-32-469-2748 TEL : 82-32-469-2748
Operation LED
Cover
12V Input power( Gray )
External input(white)
Output contact(yellow)
+12V output (orange)
GND output (brown)
FAX : 82-32-472-2712 FAX : 82-32-472-2712
인증번호: RSN-RIN-RC100
( DC12V Only )
Screw (￠4X38) : 2
Harness
2 Wires
2 Wires
2 Wires
1 Wire
1 Wire
