CYDHYTEAM HY-18 User Manual

Bluetooth 4.2
TF
Line in
Line in
USB
3.7V
USB
60HZ-20KHZ
75dB
5W
USB
ios
TF
Line in
DC 5V
FM
5V1A
5V
1A
120*80*83(mm)
Thank you for choosing our products. Please read this product manual
carefully before use.our company does not bear any responsibility for per-
sonal injury or product damage caused by improper use.
Bluetooth speaker
User Manual
Next / Volume up
Previous / Volume down
Power on/off
Play/Pause/Call
Mode switch
TF Card
USB
Charging port
AUX
luetooth model
1. Bluetooth version: Bluetooth 4.2, support ios, Android and other devices.
2. long press the power button, into Bluetooth mode, the speaker will issue
prompt tone.The machine enters the paired mobile phone and searches for
the Bluetooth pairing name. Click to connect successfully.
TF Card Mode & USB
1. Insert TF card & USB after power on, and enter TF card & USB play mo-
de automatically.
2. Pull out the TF card & USB and the speaker automatically enters Blueto-
oth mode.
Line in mode
1. Insert the Line in line after power on, and enter Line in mode automatica-
lly.
2. Pull out the Line in cable and the speaker automatically enters Bluetooth
mode.
FM radio mode
1. After booting, insert the random charging cable into the DC 5V port to act
as an external antenna.The machine enters the Bluetooth mode, short pre-
ss the switch button to enter the FM mode, short press the "+" button to en-
ter Automatic search mode, after the search is completed press "-" / "+" to
switch radio stations.
Charge
1. Insert the USB cable into the speaker. Connect the 5V1A charger to the
speaker's internal battery Charging.
2. The red LED lights up when charging, and the red light goes off when it
is full.
Function parameters
Built-in lithium battery voltage: 3.7V Charging voltage: 5V
Frequency Response: 60HZ-20KHZ Charging Current: 1A
6LJQDO WR QRLVH UDWLR •G% 6L]H    PP
Output power: 5W
Packing list
Multimedia Speaker ---- 1pc USB Charging Cable ---- 1pc
Audio Cable ----1 pc User Manual ----1 pc
