  • Page 1 Instruction Manual ® HDMI Hybrid Active Optical Cable...

  • Page 2: Intended Use

    Install Bay HDMI Hybrid AOC cable INTRODUCTION Thank you for purchasing the Install Bay Fiber Optic HDMI AOC Cable. This Cable allows you to transmit HDMI signals to a distance of up to 100m without external power supply. This cable is a hybrid cable containing both fiber optic and copper cores.
  • Page 3 Consult an expert when in doubt about the operation, safety or connection of the device. FEATURES This Install Bay HDMI AOC Cable has many features that enable it to perform in a superior manner. Among those features you will find: •Supports HDMI 2.0b specification with data rates up to 18Gbps...

  • Page 4: Specifications

    •Long-term bending radius (45mm) •Plug and Play •Low Power Consumption: 250mW (max) •No loss of signal •Delivering crystal clear digital images instantly •IB-HDAOC Series UL rated CL3 approved PVC jacket •IB-HDAOCP Series UL rated Plenum approved PVC jacket APPLICATION This product is for example applicable to: •Digital Signage •LED Signboards •Home Theater...

  • Page 5: Cross Section

    OPERATION AND CONNECTION DIAGRAM ATTENTION The Install Bay HDMI AOC is designed for use with the +5V passive power, supplied through pin 18 on the HDMI connection from the source device. This +5V connection, as well as powering the internal fiber optic module, is also carried through to the other sink via a full standard copper connection.

  • Page 6: Troubleshooting

    Install Bay AOC HDMI Cable are shut down and without power. Then you can start to connect the “source side” of the HDMI plug to the transmitter and connect the “display side” of the other HDMI plug to the receiver/display.

  • Page 7: Maintenance

    You can easily remove dust using a long-haired, soft and clean brush. WARRANTY AND LIABILITY Metra Electronics grants 1 year warranty to a new Install Bay HDMI AOC. As Metra Electronics has no influence on installation, warranty only applies to the product itself.

  • Page 8: Disposal Of The Device

    CE CONFORMITY hereby declares that the Install Bay HDMI AOC complies with Directive 2014/30/EU. DISPOSAL OF THE DEVICE WEEE-Reg. No.: DE 93847290 According to the European WEEE directive, any electrical and electronic equipment must not be disposed with consumers waste. As a consumer, you are committed by law to reposit electrical and electronic devices to public collecting points or to the dealer for free at the end of the device’s...
