Vertex Standard MH-75A8J Service Manual

16-K /DTMF M
EYPAD
MH-75
Service Manual
The MH-75 is a 16-Keypad/DTMF Microphone designed especially for Vertex Standard transceivers
A8J

Please refer to the Vertex Standard products catalog for the correct microphone for the trans-
ceiver you are using
1 2
4
7 8
0

Specifications

Mic Element:
Mic Impedance:
Operating Voltage Range:
Current Drain (Approx.):
Operating Temperature Range:
Weight (Approx.):
MH-75 Service Manual
A8J
ICROPHONE
A8J
3 A
5 6 B
9 C
D
Electret Condenser
600 Ohm
8 to 9 V DC
20 mA
–22 °F to +140 °F (–30 °C to +60 °C)
7 oz. (200 g)
