Base installation guide
Material commodity
stator
Plastic base
Damping ring
screw(six)
③
①
Please refer to picture operation method,
Please refer to picture operation method,
The stator into alignment positioning fixed hole location.
the damping ring in the column.
Concave part
lobe
④
②
Please refer to picture operation method,
Please refer to picture operation method,
Screw fixed base location piece.
Will base in the column.
front
(Behind the audience)
behind
Note:
Base distinguish between front and rear.
NOTE: This product is very heavy, assembly of 2 people above
