Installation and maintenance manual Contents PAGES 1 SAFETY PRECAUTIONS WARNINGS 2 DESCRIPTION 2.1 Dimensions 2.2 Inspection and storage 2.3 Handling the unit 3 TECHNICAL DATA 3.1 Electrical specifications 4 INSTALLATION 4.1 Installation location 4.2 Fitting the unit 5 HYDRAULIC CONNECTIONS 5.1 Hydraulic connections 5.2 Connection of the chilled water loop 5.3 Drainniag... -
Page 3: Safety Precautions
1-Safety precautions ELECTRICAL POWER MUST BE SWITCHED OFF BEFORE STARTING ANY WORK ON JUNCTION BOXES The aim of this manual is to provide instructions for installation, commissioning, operation. WARNING ! Take care ! The unit should be handled using lifting and The installation, commissioning and maintenance of these machines should be handling equipment appropriate to the unit's... -
Page 4: Description
2-Description 2.1 DIMENSIONS Models: Evo Control 8 Front view Water outlet ( 1 inch) 1015 Electric wire hole Water inlet ( 1 inch) Drainage (1/2inch) Top view... -
Page 5: Inspection And Storage
3-Technical data 2.2 INSPECTION AND STORAGE On receiving the equipment, all the elements should be checked with the packing list to ensure that no items are missing. All units should be carefully inspected on receipt for any possible damage. In the event of shipping damage, inform the shipping company and lodge a complaint by registered letter with acknowledgement of receipt. -
Page 6: Electrical Specifications
3-Technical data 3.1 ELECTRICAL SPECIFICATION Evo Control 8 Unit Model Cooling Capacity Btu/h 24200 Heating Capacity Btu/h 28000 Cooling Power Input Heating Power Input Running Current(Cooling/Heating) 10.9/8.7 Power Supply 230V~/50Hz Compressor Quantity Compressor Rotary Fan Quantity Fan Power Input Fan rotate speed... -
Page 7: Installation
4-Installation 4.1 Installation location The units are air cooled. Because of this, they must be installed outdoors in an area with sufficient clearance to provide free air circulation through the condenser coil. Any free air circulation restrictions will reduce the air flow, decrease the cooling capacity, increase the power input and, in certain cases, prevent the group from operating by excess condensation pressure. - Page 8 4-Installation WARNING ! The grill is intended to protect operators from risks of injury from the exchanger during handling and installation operations. However, it can create a risk of clogging with frost or ice on heat pump machines installed in cold or mountainous regions and exposed to the elements. To avoid such a risk, a shelter must be provided, or the protective grill can simply be removed.
- Page 9 5-Hydraulic connections 5.1 HYDRAULIC CONNECTION In choosing and installing water pipes, current local safety rules and precautions must be consulted and respected. Recommendations: The pipe circuits must be designed with minimal bends, and by reducing as far as possible the number of changes in height, in order to provide the best cost installation and guarantee the best performance.
-
Page 10: Connection Of The Chilled Water Loop
5-Hydraulic connections 5.2 CONNECTION OF THE CHILLED WATER LOOP Check, before connecting the unit, that the installation is leak free and clean. Install, manually controlled isolating valves (not provided) with a diameter corresponding to the diameter of the main pipework on the Water Inlet and Outlet connection of the unit without needing to the drain installation. -
Page 11: Hydraulic Module
5-Hydraulic connections WARNING ! It is not the manufacturer's policy to issue recommendations relating to water treatment. The user or the owner is responsible for contacting a specialised water treatment enterprise. However, water treatment is a very critical subject and special consideration should be given to it to ensure that water treatment is properly carried out to avoid problems linking to fluid circulation. -
Page 12: Electrical Connection
6-Electrical connection 6.1-Electrical connection WARNING ! Before starting any electrical connection, check that the electrical supply On site wiring must be carried out in corresponds to the specification accordance with the wiring diagram indicated on the unit's maker's plate and affixed to the unit's junction box. -
Page 13: Electricity
7-Electricity 7.1 The operation manual of the wire controller μ C SE CAREDL mute clear 1）About buttons Button Meaning Pressing this button could return back to the previous interface. mute Function1：continually pressing this button could enter into the set interface. Function2：pressing this button could enter into the next interface. -
Page 14: The Operation Of The Wire Controller
7-Electricity 7.2 The operation of the wire controller 1 Turn on/off ” or “ ”could start the unit. The screen On the state of power off, pressing(for 5s)“ displays the mode and water inlet temperature； ”or“ ”could turn off the unit. For the On the state of power on，pressing(for 5s)“... - Page 15 7-Electricity 3 Temperature setting On the state of power on or power off, you could set the heating or cooling temperature. ”and hold for 5s to enter into the parameter setting interface. Press“ ”(Up)or“ Press“ ”(Down) to choose the needed setting. Press“ ”to confirm.
-
Page 16: Parameters Table
7-Electricity 1.4 Malfunction When there is something wrong with the unit, the wire controller will display the error code according to the fault reason. For the detailed meanings of the error codes please refer to the Fault Table. For example: Water inlet fault μ... -
Page 17: Maintenance
8-Maintenance TAKE CARE ! Before proceeding with any intervention on the machine,you must be sure that the electrical supply is switched off.Servicing and maintaining the units must be carried out by qualified refrigeration technicians.Repeated triggering of safety and control devices must be thoroughly investigated and corrected before any further re-occurrence.The simplicity of the cooling circuit isolates it from any problem that might occur during operation. -
Page 18: Appendix
9-Appendix 1. Caution & Warning 1. The unit can only be repaired by qualified installer centre personnel or an authorised dealer.（for Europe market） 2. This appliance is not intended for use by persons (including children) with reduced physical sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. - Page 19 9-Appendix 2. Cable specification 1. Single phase unit Nameplate Creepage protector Signal line maximum Phase line Earth line current No more 2×1.5mm 1.5mm 30mA less than 0.1 sec than 10A 2.5mm 30mA less than 0.1 sec 10~16A 2×2.5mm 30mA less than 0.1 sec 16 ~25A 2×4mm 25 ~32A...
- Page 20 Code:20170517-0001...
