Summary of Contents for AVGO CM1551
- Page 1 Owner’s manual Avgo 400 Watt CD Mini Bookshelf Black HOUSEHOLD USE ONLY ITEM NO.NOXPS PRODUCT CODE:4NOXPSNBL0010 Made in China...
-
Page 2: Table Of Contents
Contents Features ..................2 For your Attention................3-4 Panel.....................5 Connections...................6 Remote Control................7-8 Basic Playback................9-11 Trouble shooting................12 Contents Specifications................13... -
Page 3: Features
Features Thank you for your purchase of our product. Please read through this manual before operating this product. Retain this manual for future reference. ●Compatible with CD,MP3,CD-R,CD-RW,etc. ●With USB Slot . ●Full function remote control. ●FM stereo radio tuner. Note: The player is not compatible with all discs; Some discs may not be read if the disc is dirty, or of poor quality, etc. -
Page 4: For Your Attention
For Your Attention Safety precautions The information you need to prevent danger to the user and other people as well as property damage is described below. “Descriptionof signs” shows different levels of danger or damage that may occur due to wrong handling. Important notes This book is only a guide for user's operation, not a criterion for configuration. - Page 5 For Your Attention 12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13. Unplug this apparatus during lightning storms or when unused for long periods of time.
-
Page 6: Panel
Panel FRONT PANEL: 1 DISPLAY SCREEN 2 STANDBY 3 PREVIOUS/FAST REWIND 4 SOURCE 5 PLAY/PAUSE 6 MASTER VOLUME ADJUSTER 7 LINE IN 8 USB SLOT 9 HEADPHONE 10 DISC TRAY 11 EQ 12 STOP/UNPAIR 13 OPEN/CLOSE 14 NEXT/FAST FORWARD REAR PANEL: 15 FM ANTENNA JACK 16 SPEAKER OUTPUT WARNING:... -
Page 7: Connections
Connections AUDIO SYSTEM CONNECTION Speaker Output Connect the speakers to speaker output terminals with their attached speaker cables . LINE IN This unit has an extra group of audio input terminals. You can input the analogue stereo audio signals from extra devices such as VCD, CD, VCR,MP3 player, etc. -
Page 8: Remote Control
Remote control Remote Control Operation Insert the batteries into the remote control. Point the remote control at the remote sensor on the front panel. The remote control works within a distance of about 8 metres from the sensor and within an angle of about 30 degrees from the left and right side. - Page 9 Remote Control 1 STANDBY 11 10+/TUN+ 2 BT 12 VOLUME- 3 USB 13 EQ/CLOCK 4 OPEN/CLOSE 14 FM 5 CD 15 LINE 6 FAST REWIND/ 16 PROG/MEMORY PREVIOUS 17 FAST FORWARD/NEXT 7 PLAY/PAUSE/LED 18 REPEAT/SHUFFLE 8 FOLD- 19 STOP/AUTO/UNPAIR 9 FOLD+ 20 VOLUME+ 10 10-/TUN- 21 MUTE...
-
Page 10: Basic Playback
Basic Playback CD Operation ●Press to switch on the unit. Press it again to put the unit in standby mode. ●Press to open or close the disc tray. ●Press to enter to USB mode. ●Press to enter to CD mode. ●Press to enter to LINE IN mode. - Page 11 Basic Playback ●In standby mode, hold down this button and enter into clock set mode, press[ ] button to select 12H or 24H clock display ,press clock button to confirm, then use [ button to set the clock time, press it again to confirm it. Note: it is only available in standby mode.
- Page 12 Basic Playback Tuner Operation The following buttons are used in tuner mode. Press [FM] button repeatedly to select tuner mode. ●TUN+: press to fine tune (increase) the frequency; ●TUN-: press to fine tune (decrease) the frequency. ●Hold down [TUN+/-] to increase/decrease the frequency continuously.
-
Page 13: Troubleshooting
Troubleshooting Before resorting to maintenance service, please kindly check by yourself with the following chart. Symptom Cause(s) Remedy ●The AC power cord is not ●Please check that the AC No Power connected to the power supply or is power cord is connected not connected to a power supply securely. -
Page 14: Specifications
Specifications Power supply AC ~100-240V,50/60Hz Power consumption 120W Temperature -10~+35℃ Working environment Relative humidity 5%~90% ＞80dB( S/N(A weight) 1kHz ≥70dB( Dynamic Range 1kHz ≤ -60dB(1kHz) Disc output THD+NOISE Below the limit of apparatus measure WOW FLUTTER FM band Range Tuner 87.5MHz~108MHz Power output (Max) 200WX2...
