SOLIDDRIVE SD1g Installation And Use Manual

SolidDrive SD1g Specifications
Type
Impedance
Frequency Response (Hz)
Recommended Amplifier Power
Dimensions
Weight
UL Listing
NOTE: When installed in Canada, this product must be installed in accordance
with the Canadian Electrical Code, C22.1, Part1.

WARRANTY

SolidDrives, SolidDrive subwoofers, and A4 amplifiers are guaranteed for 7 years
from date of purchase. Any misuses or modifications to this equipment in any way will
void the warranty.

WARNING

Read instructions prior to operating. To reduce the risk of fire or electric shock, do not
expose this product to rain or moisture. Unplug prior to cleaning and clean with a
damp cloth. There are no user-serviceable parts in this product, please refer all
servicing to qualified personnel.
8005 W. 110th St., Suite 208 • Overland Park, KS 66210
TEL: 913-663-5600 • FAX: 913-663-3200 • www.SolidDrive.com
REV - 3 / 3 / 11
Full Range Transducer
8 Ohm
70 Hz to 15 kHz
10 – 100 Watts
2.28'' Diameter x 2.08'' Height
Mounting Plate 3.5'' Diameter
1.2 lb / .54 kg
1480 & 2043
SolidDrive
INSTALLATION & USE GUIDE
for SolidDrive SD1g on glass surfaces
Experience Audio Perfection
Induction Dynamics extensive line of audio
products makes it easy to create the ultimate
audio system, regardless of installation
requirements. Induction Dynamics builds
these products with only the most select
components and materials; and utilizes
numerous unique and proven technologies.
INSTALLATION OF SOLIDDRIVE SD1G ON GLASS
SURFACES
By utilizing these basic installation steps, you can install
the SolidDrive SD1g on glass surfaces to create sound for
boardrooms, home theater, and distributed audio.

GETTING STARTED WITH SOLIDDRIVE

What's included with the SolidDrive SD1g for installation
on glass surfaces and what is supplied by the installer —
A SolidDrive SD1g consists of: One (1) SolidDrive SD1g
unit and attached wiring harness with Eurostyle connector.
The SolidDrive SD1g comes with a VHB double-sided
adhesive disc.
The SolidDrive SD1g can be installed on windows to deliver
sound to glass storefronts and glass reception areas. The
entire windowpane can become a speaker delivering both
interior and exterior sound on single-pane glass. For
double-pane glass, it is important to mount the SolidDrive
SD1g to the side you wish to be audible.
The SolidDrive mounted to glass works great for these
applications:
• Restaurants
• Mall stores
• Auto dealerships
• Department stores
• Stadium sky boxes
• Reception areas
• Glass atriums
• ANY pane of glass where you want
audio delivered.
