Summary of Contents for AirCom AirFlow A3X
- Page 1 Test Model：A3X...
- Page 2 DIAGRAM...
- Page 3 1. Airtube 2. Speaker Chamber 3. Controller 4. Micro USB Port 5. Rubber Noise Isolating Eartip 6. Rubber Earring 7. Magnetic Cap 8. Vol – 9. MFB (Multi-Function-Button) 10. Vol +...
-
Page 4: How To Use
HOW TO USE WARNING: DO NOT insert your in-ear earphones too deeply into your ears. Doing so may cause permanent damage to your eardrums and can interfere with sound quality. CHARGING THE EARPHONE On the controller side of earphone there is a Micro USB port cover and connect the Micro USB end of the charging cable to the Micro USB port. -
Page 5: Power On/Off
POWER ON/ OFF Power ON > Press & hold MFB for 3 seconds to power ON. LED indicator will flash once every 5 seconds Power OFF > Press & hold MFB for 3 seconds to power OFF. LED indicator will go off. WHAT IS PAIRING “Pairing”... - Page 6 Please refer to the user’s manual for your mobile phone for more information. 4. Select “Aircom” in the device list on the phone and follow the instructions to proceed. 5. If your device requests a pairing code, enter “0000”. The red LED indicator will stop flashing if pairing is successful.
-
Page 7: Playing Audio
PLAYING AUDIO Select the audio player on your source device & select play via “Aircom”. The audio will automatically start streaming to the earphone. Press MFB once to PAUSE audio & again to Play audio. Adjust volume level by pressing & holding the Volume + key or Volume –... - Page 8 HOW TO USE SELECTING TRACKS Double press the Vol + for next track Double press the Vol – for previous track NOTE: Some audio players will go back to the start point of the current track, when previous track is selected. NOTE: This function will only work properly when connected directly to a Bluetooth A2DP compatible music player.
- Page 9 ANSWERING CALLS Answer/ End incoming call > Press MFB once Redial last call > Press MFB twice Reject Call > Press & hold MFB If you are connected to and playing music from a mobile phone, a brief tone will be heard to notify you that there is an incoming call.
- Page 10 HOW TO FIT Multiple size rubber eartips S, M, L are provided. M size rubber eartip is installed from factory. Proper fit should be comfortable but create a light seal between rubber eartip and inner ear canal. Multiple size rubber earrings S, M, L are provided.
-
Page 11: Troubleshooting
TROUBLE SHOOTING NO RESPONSE · Make sure the A3X is on · Make sure the A3X is completely charged · Make sure the A3X is properly paired with the audio source UNABLE TO CONNECT WITH A PREVIOUSLY PAIRED DEVICE · Clear the pairing list on the audio source ·... -
Page 12: Care & Maintenance
CARE / MAINTENANCE The Aircom A3X is water resistant and can be washed in warm water. Hang dry with earbuds below the speaker chamber so water does not drip in to the speakers. Do not submerge in water. -
Page 13: Safety Information
SAFETY INFORMATION • To avoid damage to your hearing, we recommend that your listening level be less than 85dB. For example, conversational speech is typically around 60dB and a rock concert in a stadium is around 110dB. A decibel (dB) is a unit of measure of sound. •... - Page 14 Defects which occur within this warranty period, under normal care and use of the product shall be, at Aircom’s option, repaired or replaced, with no charge for parts or labor. Shipping and handling charges may apply except where prohibited by law.
- Page 15 FCC Warning Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. ...
