Summary of Contents for Tuzio Woodstock H6013
- Page 1 Tuzio Woodstock ® Towel Warmer Installation Guide Code: H6013 / H6014 / H6016 26.5” x 37” x 5.5” Hydronic Technical Helpline: Toll-Free 1-877-757-8990 www.icocanada.com...
- Page 2 Congratulations! You are the proud owner of a quality Tuzio Towel Warmer. This product has been specifically engineered and tested to provide optimal comfort and satisfaction. ICO carries a broad range of luxury bathroom products designed to make everyday living just a little more enjoyable! Visit www.icocanada.com to learn more.
- Page 3 Towel Warmer Installation Procedure Rough-in Requirements - for constant circulation heating system (see figure 1) Using this installation method, the towel warmer is controlled using the valves attached to the towel warmer, and can be operated independently from the heating system. This method of installation is popular where there are multiple heating appliances connected to a closed hot water heating system, and electronic control of the individual towel warmer is not important.
- Page 4 Towel Warmer Installation Procedure Rough-in Requirements - for dedicated heating system (see figure 2) Using this installation method, the towel warmer is controlled using the thermostat wired to the circulator pump, and cannot be operated independently from the heating system. This method of installation is popular where there is only one heating appliance connected to a closed hot water heating system, and electronic control of the individual towel warmer is required.
-
Page 5: Installation Instructions
Towel Warmer Installation Procedure Installation Instructions (see figure 3) 1. Check all items have been received. You should have Towel Warmer and mounting discs including fixings. Read all instructions before continuing. 2. Fix mounting discs "A" using the screws provided and in locations as shown on figure 2. 3. - Page 6 Specifications & Drawings (wall rough-in) Model # Description Finish Weight (lb) Output WxHxD (mm) WxHxD (Inches) Metal Type H6013 Woodstock Hydronic Chrome 14.0 675 x 940 x 140 26.5” x 37” x 5.5” Mild Steel 832Btu H6014 Woodstock Hydronic Brushed Nickel 14.0 832Btu 675 x 940 x 140...
- Page 7 Specifications & Drawings (floor rough-in) Model # Description Finish Weight (lb) Output WxHxD (mm) WxHxD (Inches) Metal Type H6013 Woodstock Hydronic Chrome 14.0 832Btu 675 x 940 x 140 26.5” x 37” x 5.5” Mild Steel H6014 Woodstock Hydronic Brushed Nickel 14.0 832Btu 675 x 940 x 140...
- Page 8 Towel Warmers Electric In-Floor Heating Insulation Board...
