Summary of Contents for Dojo DL0007
- Page 1 Dojo by BullGuard-DL0007 User’s Guide 9 Devonshire Square EC2M 4YF London. United Kingdom Company website: dojo.bullguard.com For information, contact: info@dojo-labs.com For support, contact: helpdesk@dojo-labs.com May 2017 ® All rights reserved.
-
Page 2: Table Of Contents
Dojo Technology ....................... 3 Further Information ......................4 Setup ............................ 5 Before You Start........................ 5 Unpacking the Dojo Pebble Kit ..................5 Setting Up Dojo ......................... 5 Using the Dojo App ......................17 Logging In ........................17 Dojo Tab ......................... 18 My Devices Tab ...................... -
Page 3: Overview
If any suspicious device tries to connect to your home router, Dojo will notify you via the Dojo app (available for Android and iOS) and you can simply block it. -
Page 4: Further Information
Behavioral Analysis: Dojo constantly monitors and analyzes the home router and connected devices. The Dojo Cybersecurity Engine is based on cutting-edge Artificial Intelligence and Machine Learning technology using sophisticated algorithms for anomaly detection and behavioral analysis. Further Information In addition to this guide, the following resources are available for information: •... -
Page 5: Setup
Setup - Before You Start Setup This chapter describes how to set up the Dojo network, install the Dojo app, register to the Dojo service and discover the devices in your network. Before You Start Before you begin to set up the Dojo Pebble, ensure that you have the following: •... - Page 6 Registering a New Dojo User and Pairing the Dojo App with the Dojo Base Unit Step 1: Connecting the Dojo Base Unit to the Router There are two modes for connecting the Dojo base unit to the router, depending on the way your home network is set up: •...
- Page 7 Setup - Setting Up Dojo Router Mode 1. Plug the AC adapter into the Dojo Base Unit as shown in Figure 4, then connect the adapter to a power outlet. Figure 4: Router mode power connection 2. Plug one end of the Ethernet cable into the ETH2 port of the Dojo Base Unit, as shown in Figure 5, then plug the other end into an available port in the router.
- Page 8 3. Insert four AA batteries into the battery holder. Ensure they are aligned properly. Close the battery cover. 4. Turn on the Pebble: Press and hold down the button located next to the Dojo logo for 3 long seconds. Red, Green, and Blue circles flash to indicate that the Pebble is powering on.
- Page 9 Setup - Setting Up Dojo Figure 7: Push notifications screen 2. Select Allow push notifications to receive alerts from Dojo. 3. Select Register. Figure 8: Registration screen 4. Select Register.
- Page 10 Dojo Base Unit to the Router, on page 6, touch Click Here When You’re Done. Wait for the app to display Successfully connected to Dojo. Figure 10: Successful Dojo connection screen 5. Select Let’s Start to begin registration.
- Page 11 Note: The email is also used as your username and cannot be changed once the Dojo is registered. Make sure you are satisfied with the email address that you are going to enter. 7. iPhone users: To enable sign in with Touch-Id, select the Allows login with Touch ID check box.
- Page 12 Setup - Setting Up Dojo Figure 10: Confirmation screen 10. Check your email for a message that contains a six-digit PIN code. Enter the PIN code into this screen, then select Submit. Figure 11: Account verification screen 11. Select Next.
- Page 13 Setup - Setting Up Dojo Figure 15: Installation mode screen In this screen, you may select either Router Mode or Bridge Mode, according to the network configuration you set up earlier: 12. Select a mode, then touch Next. Figure 12: Installation mode confirmation screen...
- Page 14 Figure 13: Home Router admin screen 14. In this screen, you may select one of the following options: • Let Dojo set your router remotely. In this case, enter your home router admin credentials. • Change the home router setting manually, on your own. In this case, you do not enter the credentials, and instead, select the check box next to I’ll change my home...
- Page 15 You’re Done to proceed. Figure 19: Dojo is analyzing network screen 17. Dojo begins to analyze your network. This process may take several minutes. When Dojo completes the analysis, a notification will be sent to your smartphone and the following screen is will be displayed.
- Page 16 1. Log into the home router admin page. 2. Disable the DHCP server. 3. Apply the changes. 4. Restart the router. Discovering Devices in Your Network Once the Dojo Base Unit is activated and ready, it scans your home network to discover all connected devices.
-
Page 17: Using The Dojo App
Figure 21: My Devices tab Note: Dojo places a new device in the Guests group until you move it into another group. Using the Dojo App This chapter will guide you on how to use the Dojo app. -
Page 18: Dojo Tab
The Dojo tab is displayed. Dojo Tab The Dojo tab is the main screen of the app and shows the recent activity relating to devices in your network. The activity is communicated to you via the Dojo Bot in the form of chat. - Page 19 Using the Dojo App - My Devices Tab Figure 23: My Devices tab Each device has the following markings: • Device name • Device type. For example, a router has the following icon: • Device activity. An active device is marked with three moving dots: ;...
-
Page 20: Device Groups
• By touching a specific device, you can see detailed information about it (at the top of the screen), as well as the recent Dojo monitoring activity relating to the device (at the bottom of the screen). Figure 17: Device details •... -
Page 21: Changing Groups
• Devices are not allowed to configure the router. • To enable a device to bypass Dojo entirely, you can move it from its current group to the Unprotected group. Changing Groups You can change the group to which a device belongs. There are two ways to do this: by... - Page 22 Using the Dojo App - My Devices Tab By Dragging a Device 1. Select the My Devices tab. 2. Select Edit. 3. Drag the required device from one group to the other, by holding down its drag handle. Figure 25: Group move confirmation 4.
-
Page 23: Editing Device Details
Internet. Figure 29: Block switch on • Device Name: Dojo displays the default device name. To change it, select the name and edit as needed. • Device Type: Dojo displays the default device type. To change it, select the arrow next... -
Page 24: Alerts And Actions
In the event of a Red alert, a Red activity message is communicated by the Dojo Bot via the Dojo app, and the Pebble lights up in Red. - Page 25 Orange notifications: These messages merely inform you that the Dojo service has handled the event. In the event of an Orange alert, an orange activity message is communicated by the Dojo Bot via the Dojo app, and the Pebble lights up in Orange. Example of Alerts and Actions In the event of an unauthorized attempt of a device to access your network, a Red alert is communicated via the Dojo Bot.
-
Page 26: Removing An Action From A Device
Once the action is blocked, you will not be notified again about the specific device, and it will always be blocked from accessing the router. 2. For example, if Allow Once is selected, Dojo displays your selection, then follows up with a confirmation:... -
Page 27: Dojo Menu
Using the Dojo App - Dojo Menu Dojo Menu Figure 36: Menu button Select the Menu button in the top left corner of the app to access your Dojo account, Dojo app settings, and online help and support. Figure 37: Dojo menu •... - Page 28 Using the Dojo App - Dojo Menu Figure 38: My Account screen • Select Settings to display a screen where you can change Dojo app settings. Figure 39: Dojo app settings screen • Select Help/Support to display the Dojo Help and Support site.
-
Page 29: Protecting A Device With Remote Access
Let’s say that you have set up remote access to a protected camera in your home network so that you can monitor activity from the office. To continue using this setup with Dojo, you must change the settings in the home router and the Dojo app. -
Page 30: Regulatory Compliance Information
Regulatory Compliance Information Technical Specification Base Unit Power Supply: Input 110-240 VAC / Output 12V DC 1.67 A 20 W Operating temperature: 0 - 35 degrees C / 32 – 95 degrees F Pebble Power 4xAA size batteries (not included) Operating temperature: 0 - 35 degrees C / 32 –... -
Page 31: Ic Statement
Regulatory Compliance Information - IC Statement (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 32 Regulatory Compliance Information - CE Declaration of Conformity (DoC) Hereby, BullGuard Israel LTD declares that the radio equipment type [designation of type of radio equipment] is in compliance with Directive 2014/53/EU.” Customers can download a copy of the original DoC to our RE products from < exact Internet address where the full text of the EU declaration of conformity can be obtained.
