Summary of Contents for BION TECHNOLOGIES cambium xl
- Page 1 USER MANUAL BEDIENUNGSANLEITUNG www.biontechnologies.com...
-
Page 2: Safety Instructions
USER MANUAL cambium xl Safety Instructions Devices must be installed by qualified personnel in compliance with all pertaining regulations. Always refer to the technical parameters in the data sheet. All items are subject to technical modification. Refer to the attached User Manual as a basis for correct use. -
Page 3: Scope Of Delivery
Scope of delivery Check completeness of supplied device immediately after receipt. In delivery included: cambium xl - device Power Supply CD with Software User Manual If you detect any transportation damage or differencies between specified packing contents and your unpacked delivery, please contact your dealer immediately. -
Page 4: Technical Data
Technical Data Dimensions 106 mm x 146 mm x 11 mm 4.17 in x 5.75 in x 0.43 in Control Output: 2 x DMX 512 (1024 DMX Channels) Input: 8 potential-free inputs binary configurable (255 Trigger) Input Voltage Power supply: external 5 - 6 VDC Operating Temperature Range 0 °C / +50 °C | 32 °F - 122°F... - Page 5 Mounting www.biontechnologies.com | 5...
- Page 6 Commissioning RS232 Triggering Make a cable using the 3 pins : TX, RX and G (GND) Set the RS232 parameters to : 9600bds 8 bits, no Parity, 2 Stop bits To play a scene, send 3 bytes : 1 x y 255 To stop a scene, send 3 bytes : 2 x y 255 To pause a scene, send 3 bytes : 3 x y 255 To release a pause, send 3 bytes : 4 x y 255...
-
Page 7: Operation
Operation 1. Setting up the Controller iPhone/iPad/Android Control The controller can be used with one of 3 different apps. Each available at Google Play and the App store. DMX Lightpad 3 Designed to work seamlessly with the controller, DMX Lightpad 3 provides an easy way to control your lights over a local WiFi network. Use the wheel to change the dimmer, color or speed, and the arrows to select scenes and effects just like the wall panel. - Page 8 Battery - used to store the clock/calendar DMX Chips - used to drive the DMX To replace the Li-Ion rechargeable battery on the cambium xl: 1. You need a rechargeable 3.6v LIR 2032 replacement battery 2. Remove the back panel by pulling down and sliding it out.
- Page 9 S Auto reset : when enabled, any color, dimmer or speed overrides will be reset each time the scene is changed S Trigger : sets the scene triggering mode. Time Delay and Scene Butt allow for scenes to be scrolled through without playing Auto : the scene will be triggered as soon as it’s selected Time Delay : a short delay is added before a scene is triggered Scene Butt.
-
Page 10: Maintenance
Clean device from dirt and residue regularly. Use solvent-free cleaning agents only and do not employ aggressive chemicals or high pressure cleaner. Operate device only after complete drying. Conformity Manufacturer Bion Technologies GmbH Lindberghstrasse 15 86343 Koenigsbrunn Tel: +49 (0)8231/95787-0 Fax: +49 (0)8231/95787-29 www.biontechnologies.com... - Page 11 Lindberghstrasse 15 86343 Koenigsbrunn Tel: +49 (0)8231/95787-0 Fax: +49 (0)8231/95787-29 www.biontechnologies.com info@biontechnologies.com YouTube: http://www.youtube.com/user/BIONTECHNOLOGIES © 2016, BION TECHNOLOGIS GMBH All rights reserved / Subject to change / Specifications may change without notice...
