iSTAT M3x5/EN/M/B © 2014. ALSTOM, the ALSTOM logo and any alternative version thereof are trademarks and service marks of ALSTOM. The other names
mentioned, registered or not, are the property of their respective companies. The technical and other data contained in this document is provided for information only.
Neither ALSTOM, its officers or employees accept responsibility for, or should be taken as making any representation or warranty (whether express or implied), as to
the accuracy or completeness of such data or the achievement of any projected performance criteria where these are indicated. ALSTOM reserves the right to revise or
change this data at any time without further notice.
iSTAT M3x5
Power Quality Analyser
Manual
iSTAT M3x5
Power Quality Analyser
Publication Reference:
iSTAT M3x5/EN/M/B
GRID
