Summary of Contents for Homeguard HGWVD-730
- Page 1 Doorcam User Manual www.vstarcam.com...
- Page 2 Function and Features ◎Visitor records, visitor snapshot and other information are stored in the cloud, user can check at anytime, anywhere; ◎Press doorcam, will automatically snapshot and push to the smartphone APP; ◎CMOS image sensor; ◎Easy to install, can use 3M adhesive paste installation or screw fixation; ◎Ultra-low power consumption, 2pcs AAA batteries can last for one year;...
- Page 3 Meaning of indoor indicator light： Network indicator Key light（blue） Meaning light（red） Flash once per sec Waiting for WiFi configuration Stable on WiFi configuration success Stable on Flash once per sec WiFiconfiguration failure Flash quickly Code pairing Stable on Flash slowly Switch ringtone and volume Flash Stable on...
- Page 4 III. Product introduction Outdoor Unit CoverCover LensTake snapshot of visitors lightWhen the light is not enough, auto fill the light,optimize the capture effect. Doorbell ButtonVisitors press the button and the indoor unit rings and take snaps of visitors. IV. Connect the Doorbell Please follow these steps to install the doorbell: Step 1:Open the box and take out the indoor unit, outdoor unit and accessories.
- Page 5 After powered on, the indoor unit makes two dingdong sound, the key light will be on and go out after 2 seconds. Note: Please plug in the indoor unit in the socket 5 meters away from the router. 英 6 Step 4: Take the outdoor unit together with the indoor unit(within two meters), make sure they are commnucating with each other.
- Page 6 2. Code Pairing（To pair the indoor and outdoor units） Note: Please follow the steps below, to press the indoor unit first and then press the outdoor unit. Don't press them at the same time. Step 1: Indoor unit To press the function key of the indoor unit three times quickly, it will make doorbell sound and the red network indicator will flash quickly, then it will enter waiting code 英...
- Page 7 Connection Topology VII. Add the doorbell to the APP 1、Software download ① Go to Google Play or Apple Store to search „Eye4‟ and to download. ② Visit [http://www.eye4.so] for software download and install. ③ Scan QR code to download. 2、Register account For android / iOS client APP, please select “Register now”, click to enter the registration page, enter user name, password, then confirm to complete the registration.
- Page 8 3、Add device Add indoor unit to the APP for mobile phone Please refer to the steps ①②③ below in sequence. ① Login the APP, click on “+”on the top right corner. There are two ways to add the doorbell: A. To scan QR code. Tap the„To scan QR code‟and scan the QR code on the label of the indoor unit, then follow the prompt on the APP, go to step ②.
- Page 9 Attention: If the indicator does not flash at once per second, please reset the indoor unit. 【Reset method: Please refer to the reset method in chapter VIII】 ② The step ② for different phones are as follows: Android devices To add the doorbell for the first time, please select the WiFi that the phone connected and input the WiFi password, then go to next.
- Page 10 Note：1. After the indoor unit being successfully bound to the APP, the red network indicator on the indoor unit will be steady on. If the indicator display abnormally or the device does not work properly, please check the connection and try to reset the device and re-add it. 2.
- Page 11 Note: The ‘share’ is the way that the host user share the QR code and other users with different account scan it to add the doorbell. 图 23-1 和 23-2（二维码打马赛克） ③ Multiple Ringtones.In addition to the default tinkling ringtone,there are 6 extra sweet ringtones to choose from, users can choose the 图...
- Page 12 6.Installation After finishing the settings, please install the outdoor unit on the wall or the door. There are two ways to install the doorbell: 3M glue fixing and screw mounting. Install the outdoor unit to the wall A. 3M Glue Fixing Remove the 3M release paper from the back of the outdoor unit.
- Page 13 7. Battery Change If you want to replace the battery, please unscrew the screws at the bottom of the cover, take out the outdoor unit, open the back cover (see below diagram), replace the batteries. After the battery is replaced, close the back cover and put it back to the rainproof shell. (see pictures below for details).
- Page 14 -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna.
