User Guide

Gululu Interactive Bottle

BWT1804

Manufacture:Kunshan Rewon Electronic Technology Co.,Ltd.

Table of Contents

Need help?

Do you have a question about the BWT1804 and is the answer not in the manual?

Questions and answers

Summary of Contents for Gululu BWT1804

Page 1 User Guide Gululu Interactive Bottle BWT1804 Manufacture:Kunshan Rewon Electronic Technology Co.,Ltd.
Page 2: Table Of Contents
CONTENTS PRODUCT INTRODUCTION GETTING STARTED FEATURES USING THE GULULU APP USING YOUR GULULU GO CLEANING SAFETY MATTERS WARRANTY TECH SPECS CERTIFICATION SUPPORT...
Page 3 This product is designed for children aged 3 and above. To ensure successful match and correct use of Gululu, please read this guide carefully. Keep this guide properly for future reference. Please visit www.mygululu.com/support for more information and FAQ Warning: Improper use may present choking hazards. This product includes tiny parts and is therefore not applicable among children under 3.
Page 4 AT A GLANCE What’s in the box Gululu Go Magnetic charging cable User Guide...
Page 5 FEATURE OVERVIEW What makes up the bottle Main Button Touch Sensor Panels Touch Sensor Panels Screen Bottle Speaker...
Page 6 How to charge your bottle 100-240V 50/60Hz 5V/1A (Adaptor included) Magnetic charging cable...
Page 7: Getting Started
GETTING STARTED 1. Long press the home key to start Gululu. In the case of powering oﬀ, please charge it for 20 minutes and try again. 2. Download Gululu App. 3. Finish registering and creating the child’ s proﬁle as instructed by the App, and select the favored Gululu Water Fairy.
Page 8: Using The Gululu App
USING THE GULULU APP 1. Create proﬁle for the child: enter the date of birth and the weight of the children. The App shall recommend the proper amount of water intake based on the age and the weight. AT&T 9:41 AM 100% AT&T...
Page 9 2. Match the bottle: click on 「+」 on the right side of the Water Fairy and “match” the bottle with the proﬁle of the child by following instructions. Check water intake history, add friends and download the latest games after successful match.
Page 10 3. Check the amount of water intake: the bottle shall get connected to the set Wi-Fi and upload the water intake history onto the Cloud and sync to App. AT&T 9:41 AM 100% AT&T 9:41 AM 100% AT&T 9:41 AM 100% Kid’s name Kid’s name...
Page 11 Modify the Wi-Fi settings to connect the bottle to the Wi-Fi in the current environment. Gululu can memorize 6 Wi-Fi addresses at most. When the bottle is connected to the 7th new Wi-Fi address, it shall delete the 1st Wi-Fi address.
Page 12 5. View and update the proﬁle of the child: click on the icon of the child to view all children and their bottles. Click on「+」to update the proﬁle of the child and match the Gululu for the child. Each account shall host the proﬁles of 21 children. AT&T...
Page 13 6. Delete the proﬁle of the child: click on in the top right corner Proﬁle click on in the lower right corner to delete the proﬁle of the child. AT&T 9:41 AM 100% AT&T 9:41 AM 100% Kid’s name Today’s latest update: 3:26 PM 1200 Friends...
Page 14 7. Set class hours: Gululu shall disenable all interactive features during class hours so that the children shall focus on learning. (But the water intake shall be recorded!) Be noted to charge the bottle for 10 to 15 minutes after updating the settings so that the bottle can receive the directive.
Page 15 8. Set the bed time: the pet shall go to sleep during the sleeping hours, which leaves the child undisturbed and encouraged the child to sleep early and get up early. Be noted to charge the bottle for 10 to 15 minutes after updating the settings so that the bottle can receive the directive.
Page 16 Q: Should Gululu be turned on? A: No. The screen of Gululu shall go black and turn into the ready mode if there is no interaction for over 1 minute. After being fully charged, Gululu shall operate for 2 to 3 days under the normal use condition and for 4 to 5 days under the ready mode.
Page 17 10. Water temperature alarm: Gululu is set with the water temperature sensor and shall alarm when the temperature is above 40°C.
Page 18 USING YOUR GULULU INTERACTIVE BOTTLE Power on: long press the home key until the boot animation appears. Pet page: the map that the pet is exploring about. In the top left corner is the level of the pet; at the top of the map is the daily water intake process;...
Page 19 Interaction in the pet page: slide the right side of the bottle to give play to the skills of the pet; and slide the left side to ascend or descend to the unlocked areas in the map. The water intake process bar shows the amount of the water that has been drunk.
Page 20 Navigation page: slide upwards or downwards of either sides of the bottle, or slant leftwards or rightwards to switch among subpages; press the home key to get redirected to every subpage; shake the bottle slightly to return to the previous page;...
Page 21 System setting page: Slide upwards or downwards either sides of the bottle to switch among items. Press the home key to select the item. Wi-Fi illustration ID illustration: (Check Gululu ID. (White: connected to Wi-Fi; Press the home key again to exit.) grey: not connected to Wi-Fi.)
Page 22 Add friends: shake two Gululus nearby at the same time to add each other as friends. The the water fairy of one Gululu will jump onto the screen of the other Gululu to paly with another water fairy. (The jumping direction is random.) Add remote friends: enter the e-mail into App to invite friends if they are not around you.
Page 23 Information syncing: the bottle will automatically connect to the set Wi-Fi and upload the water intake history to the Cloud and sync it to App. Be noted that both the server and the network condition shall change the syncing speed. The syncing might take 10 to 15 minutes.
Page 24 Battery Status——If the b attery r uns l ow, appears o n the screen. Battery status is also shown on the Journey Map page. When t he bottle i s b eing charged, will ...
Page 25: Cleaning
CLEANING Clean the whole bottle with the cleanser, sponge and soft brush but do not put the bottle into the dishwasher, the dish-dryer, the fridge or the microwave.
Page 26 CLEANING TIPS 1. Dry the bottle with natural air after cleaning up and leave the bottle open so as to avoid bacteria. 2. Do not use hard brushes or hot water during the cleaning. 3. Do not soak the bottle with hot water. 4.
Page 27: Safety Matters
Damages of any of the part might results in ﬁre, electric shock or other dangers. Please stop using the bottle immediately. Adult supervision is needed when Gululu is in the charging condition. Regulations on electronic products with low-power wave radiation Article 12: Once the product is certiﬁed as qualiﬁed electronic...
Page 28 The use of electronic products with low power wave radiation shall not impact ﬂight safety or disturbs legitimate communication. Use the product at the area where no disturbance is created once spotting any disturbance. Legitimate communication aforesaid refers to the legal communication activities that follow the Telecommunication Law.
Page 29: Tech Specs
A m e r i c a w i t h n o B PA i n t h e l i n e r, m e e t i n g t h e F DA requirements. Protection grade: dust-resistant and water resistant Gululu Go Weight: 340g / 0.75lb Volume: 380ml / 13oz...
Page 30: Certification
Wireless Charging Dock—Input: 5V,1A (Use a power adapter compliant with applicable country regulations and speciﬁcations) Battery—Capacity: 950mAh Charge time: 3 hours of charging provides 2 to 3 days of ordinary use or 4 to 5 days of standby Wi-Fi—802.1 b/g/n CERTIFICATION...
Page 31: Support
SUPPORT Please visit www.mygululu.com/support for FAQ, or contact the Customer Service in Help of the App. Love, Team Gululu Support...
Page 32 US and other countries. App Store is a service mark of Apple Inc. Android, Google Play and the Google Play logo are trademarks of Google Inc. Visit www.mygululu.com for more information on how to use Gululu Interactive Bottle and Gululu App. First edition printed in China...
Page 33 FCC Caution. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
