Summary of Contents for Yinuo-Link YN-Q300N-B1
- Page 1 YN-Q300N-B1 WiFi Router Module...
- Page 2 300M Router Module Description: YN-Q300N-B1 is one WiFi Router Module based on QCA9531 chip design, with high-performance and small size design. This item supports large capacity DDR2 and high speed SPI Flash, can connected to the motherboard by "Pin". The user can make multiplex structural design according to the mold ID and board type.
- Page 3 ·802.11b：DSSS (CCK, DQPSK, DBPSK) Modulation Type ·802.11g/n： (BPSK, QPSK, 16QAM, 64QAM) ·802.11b：11, 5.5, 2, 1Mbps Wireless Signal ·802.11g：54, 48, 36, 24, 18, 12, 9, 6Mbps Rates ·802.11n：300Mbps(Max) Transmitting Power 15 ±2dBm Receiver Sensitivity -72±1.0dBm Software Systems Shenzhen Yinuo-Link Tech Co., Ltd...
- Page 4 Definition of Pin BOTTOM J3 1*11 Pin Header (2.0mm) Pin No Symbol Type Description GPIO12 GPO Function 3.3V DC 3.3V Power Supply UPHY_DP USB Port0 Data Pin Data+ UPHY_DN USB Port0 Data Pin Data- Ground Pin Shenzhen Yinuo-Link Tech Co., Ltd...
- Page 5 2.0V Power Supply UART_TX UART Lite ×1 UART Lite ×1 UART_RX Ground Pin P4_RX+ 10/100 PHY Port #4 RXP P4_RX- 10/100 PHY Port #4 RXN P4_TX+ 10/100 PHY Port #4 TXP P4_TX- 10/100 PHY Port #4 TXN Shenzhen Yinuo-Link Tech Co., Ltd...
- Page 6 WiFiRanger Sky4 User Manual LinOra Corporation Revision 001 Limited Single-modular Transmitter Common Base-board The SKY4 module is designed to only be utilized in the WiFiRanger Sky4 shown below. Figure 3: Sky4 / Sky4 LP Top View of Common Base-board which Hosts the SKY4 Module SKY4-UM-001...
- Page 7 WiFiRanger Sky4 User Manual LinOra Corporation Revision 001 Assembled Products The EUT are produced with a standard PVC enclosure that does not affect wireless transmission and reception characteristics. Assembled Sky4 LP The Sky4 LP has both internal 5dBi antennas mounted within the base of the PVC enclosure facing out in opposite directions. ...
-
Page 8: Fcc Statement
WiFiRanger Sky4 User Manual LinOra Corporation Revision 001 FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
