KT-LCD8H E-Bike Display User Manual
Dear customer, please read this manual before you use KT-LCD8HDisplay. The manual will guide you use the instrument
correctly to achieve a variety of vehicle control and vehicle status displays.

Functions and Display

Instruments using the structure form of instrument body portion and the operation buttons are
designed separately.
1 UP Button
2 SW Button
3 DOWN Button
MOTOR W
4 Power display
ASSIST
Pas level
5
6Km/H push power assist
THROTTLE
6 Run sign
7 Battery capacity indicator
VOL
8 Battery voltage
9 The brake display

1. Operation

1. ON/OFF
Hold button long to turn on the power, and hold
the power. When the motor stops driving and when the e-bike is not used for a consecutive 5
minutes, it will automatically shut down and turn off the motor power supply.

2. Display 1

Hold

2.1 Turn on backlight and headlights

Hold
should have headlight drive output function); hold
turn off the backlight and headlights.
10 Backlight and headlights
℃
Environment temperature
11
℉
Environment fahrenheit
Km/H
12 Riding speed(metric)
AVS
Average speed
13
MXS
MAX speed
DST
Trip distance
14
ODO
Total distance
TIM
Single trip time
15
TTM
Total trip time
long for a second time to turn off
button to start up and enter display .
long to turn on backlight and headlights (the controller
long again to

2.2 Assist ratio gear (ASSIST) switch

Press
the minimum power, gear 5 is for the highest power. Each
startup will automatically restore the gear shutdown last time
(the user can set randomly). Gear 0 is without booster
function.

2.3 6Km/H assist promotion function

Hold
not more than 6Km /h. Release
invalid.

2.4 Display and delete of single data

After power on for 5 seconds, hold
same time, single trip riding time (TM) and single trip distance
(DST) flash, hold
cleared. If failed holding the button within 5 seconds, it will
automatically return the display interface after 5 seconds,
original content is preserved.
3.Display 2
Press
In the riding mode after 5 seconds, display 2 automatically
returns to display 1, and the original motor power (MOTOR
W) display is replaced with motor operating temperature
display (MOTOR ℃) display (the internal motor should be
equipped with the temperature sensor and the output of temperature detection signal).
4.Display 3
Press
In the riding condition, five seconds later, a single maximum
speed (MXS) display automatically returns to the real riding
speed (Km/H).
5. In display 3, hold
display will re-enter display 1.
or to switch 1-5 file gear. Gear 1 is for
and flashes, the vehicle drives at the speed
button, the function is
and at the
button shortly, the content of both is
button in display 1 to enter display 2.
button in display 2 to enter display 3.
button shortly (SW),and the
