- Page 1 Reference Manual Only models bearing the NSF logo and designated PS1-XX are certified to NSF/ANSI Standards 40 and 245 Call: 336-547-9338 or visit: anuainternational.com © 2016 Anua 6-2016...
-
Page 2: Table Of Contents
11.0 Owner Use 12.0 Owner’s Duties 13.0 Owner Checklist 14.0 Warranty for PuraSys SBR If you require further information, please contact customer service at: P.O. Box 77457 Greensboro, NC 27417 T: 336-547-9338 F: 336-547-8559 info@anuainternational.com Call: 336-547-9338 or visit: anuainternational.com... -
Page 3: What's In The Box
What’s in the Box? PuraSys SBR Models PS1-4 through PS1-8 (≤800 gpd) include (1) Novair 200 Aerator. PuraSys SBR Models PS1-9 through PS1-14 (≤1,400 gpd) include (1) Novair 600 Aerator. Additionally, each system comes in a box with the following components:... -
Page 4: Process Overview
State or Local requirements for septic tank sizing. Figure 3 Pretreatment or Septic Tank Reactor Chamber or Tank (1 chamber tank. Examples include septic tank, pump tank, or holding tank. For 2 chamber configuration, contact Anua) Call: 336-547-9338 or visit: anuainternational.com... -
Page 5: Reactor Chamber Or Tank Sizing
_______________________________________________ NOTE: The minimum and maximum volumes in these tables are guidelines for standard kits. The volumes can vary from the values in the table. Consult with Anua for alternate designs. Clear Water Pump The clear water pump (discharge pump) is an integral part of the system. This is advantageous since the SBR is essentially a primary tank, treatment unit, and pump tank all-in-one. - Page 6 Emergency Storage and Alarm Conditions PuraSys SBR controls the movement of effluent through the system in a timed sequence of batches. PuraSys SBR incorporates a clear water discharge pump. Since treated effluent is timed dosed from the system, adequate emergency storage must be provided.
- Page 7 2. Two Tanks Configuration The total emergency storage volume is calculated based on the available volume in the pretreatment tank above the normal operating level to the inside tank lid. In some jurisdictions, the riser volume can be counted for emergency storage. Emergency storage can be calculated as follows: Pretreatment tank: Determine the volume between the top siphon hole to the top of...
-
Page 8: System Installation
Pumping (inches) (inches) (inches) typical drawings for _____________________________________________________________________ further details on layout. ________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________ 1/3 or 33% ________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________ _____________________________________________________________________ NOTE: For tank depths <36" or >54", please consult Anua. Call: 336-547-9338 or visit: anuainternational.com... -
Page 9: Reactor Tank
Reactor Tank (if applicable, for two tank systems) Supply and install the reactor tank in accordance with applicable State or Local regulations. The reactor tank must be watertight against ground or surface water infiltration and/or exfiltration. Install reactor tank on stable, compacted fill (e.g. stone ≤1” or similar material). Reactor tank must be backfilled with suitable material as recommended by the manufacturer. -
Page 10: System Wiring
System Wiring The cables are coded to match the connections between the aerator, pumps, and float switches to the junction box and control panel. The smart control panel is housed in a NEMA 4X enclosure. The wiring diagram and instructions are located inside the panel. Incoming power must be 240V, 1 Phase and 120V, 1 Phase. -
Page 11: Reactor Plumbing
Reactor Plumbing Siphon/sludge pump and clear water pump must be plumbed with quick disconnects. Unions are included in the kit. If you are not using an air break on the clear water pump discharge pipe, then install a check valve. In cold weather climates subject to freezing, slope clear water pump pressure line for drainback to reactor chamber/tank and do not install a check valve. -
Page 12: Maintenance
Maintenance Maintenance steps: 1. Check the smart control panel for alarms or for errors. 2. Check pretreatment tank and take a sludge reading (see right). 3. Open reactor chamber lid. Check for noxious odor and take a sludge sample 4. If the system is in sedimentation mode and prior to clear water discharge, you may be able to perform a clarity test (see Section 9.1). -
Page 13: Troubleshooting
10.0 Troubleshooting Mechanical failure may be pumps, aerator, or float switches Replace failed component Test component for proper operation Field Issue Determine if there is a blockage or break in any lines. Check for signs of high groundwater Check for signs of damage by animals or insects Check for signs of damage by any type of motor vehicle Check for signs of damage by any plant or tree root intrusion Infiltration or Exfiltration... -
Page 14: Owner Use
The owner “Do’s and Don’ts” for PuraSys SBR are similar to a typical septic tank system. Many owner “Do’s and Don’ts” guides for septic tank systems are available online. -
Page 15: Owner Checklist
The owner is required to use and maintain the system in accordance with the guidelines contained within this manual. The owner should not have anyone work on the PuraSys SBR system except an authorized service provider. The owner is ultimately responsible to file any reports or other documentation required by the regulatory authority. - Page 16 Warranty Warranty: Anua warranties the PuraSys SBR for a period of two years, unless otherwise specified by the regulatory authority, from the date of delivery. This warranty is subject to the Terms and Conditions section and the PuraSys SBR being operated in accordance with the parameters outlined in this manual and the owner complying with the parameters outlined in this manual.
