Technical Specification
DESKO PENTA Scanner
DESKO GmbH
Gottlieb-Keim-Str. 56
95448 Bayreuth
GERMANY
Phone:
+49 (0)921/79279-0
Fax:
+49 (0)921/79279-14
E-mail:
info@desko.com
Web:
www.desko.com
Technical Support:
E-mail:
support@desko.com
Technical Specification
PENTA Scanner
®
PENTA Scannner
| Online:
www.desko.com/support
Doc # 7 001 020 101
®
®
| Phone: +49 (0) 921 79279-69
Doc.-Rev.: 2018-05-24
Page 1 of 21
Advertisement
Table of Contents
Related Manuals for DESKO PENTA Scanner
Summary of Contents for DESKO PENTA Scanner
- Page 1 Technical Specification ® DESKO PENTA Scanner ® PENTA Scannner DESKO GmbH Gottlieb-Keim-Str. 56 95448 Bayreuth GERMANY Phone: +49 (0)921/79279-0 Fax: +49 (0)921/79279-14 E-mail: info@desko.com Web: www.desko.com Technical Support: E-mail: support@desko.com | Online: www.desko.com/support | Phone: +49 (0) 921 79279-69 Technical Specification...
-
Page 2: Table Of Contents
Handling the DESKO PENTA Scanner .................. 4 Package Content ........................ 4 Introduction ..........................5 Features ............................. 6 Key Features of the DESKO PENTA Scanner ................ 6 OCR Recognition ......................6 ID Document Image Scanning..................6 Status LEDs ......................... 7 Buzzer ......................... 7 PERLUCOR ®... -
Page 3: Desko Official Explanation Of Abbreviations
DESKO Official Explanation of Abbreviations 1D Code Linear or one-dimensional Barcode 2D Code Two-dimensional Barcode Application Programming Interface Basic Access Control Barcode Barcode Reader Dynamic Link Library Dots Per Inch DUKPT Derived Unique Key per Transaction ICAO International Civil Aviation Organization... -
Page 4: Security Advice, Handling Rules & Package Content
Security Advice • The DESKO PENTA Scanner family contains UV-A and IR light sources which are classified as CLASS 1M LED PRODUCT according to IEC 60825-1. That means that the light sources radiate intense invisible UV-A from IR light during the scan process. -
Page 5: Introduction
Quick Installation Guide or need access to our download area. The PENTA Scanner is a full-page scanner designed to be used in self-service and agent operated environments. As an intelligent device, it supports OCR, barcode and magnetic stripe reading (depending on hardware configuration) within the device itself. -
Page 6: Features
Features Key Features of the DESKO PENTA Scanner The PENTA Scanner is a multi-document reader. It supports various document types like passport or boarding passes. The actual features are depending on the hardware configuration. OCR Recognition The integrated ICAO document reader is capable of reading and decoding OCR data with a read rate of at least 99% from the following documents: •... -
Page 7: Status Leds
(optional feature) Status LEDs The PENTA Scanner has two integrated multicolor LEDs on the front. The right LED shows the power connection status of the device. The left LED is for custom use and can be controlled by the application using the device API. -
Page 8: Rfid & Nfc Reading
ISO 7811/2-5. Integrated Chip Card Reader The PENTA Scanner Chip Card Reader is compliant to ISO 7816 and EMV² 2000 level 1 and designed for reading synchronous and asynchronous chip cards with the following standards:... -
Page 9: Hardware Integration And Setup
Hardware Integration and Setup To use the PENTA Scanner, it needs to be connected to the power supply and the according host interface which is usually the USB port driven by the DESKO Page Scan API (see chapter 5.1 Connecting via Page Scan API). -
Page 10: Hardware Setup
Hardware Setup Step 1 – Power Connection Connect the PENTA Scanner to the power plug (orange box). Only use the provided power supply! Step 2 – Signal Connection Connect the PENTA Scanner via the provided USB cable with your PC (green box). -
Page 11: Software Integration
Connecting via Page Scan API To get access to all features of the PENTA Scanner, it needs to be connected via the USB host interface and addressed via the DESKO Page Scan API. This API is included in the device SDK which provides drivers for Windows 7, 8, 8.1 and 10, 32 bit and 64 bit as well as libraries and sample applications for... - Page 12 To obtain optimal read results, the barcode should be placed in the middle of the scan window. Technical Specification Page 12 of 21 PENTA Scanner Doc # 7 001 020 101 Doc.-Rev.: 2018-05-24 ®...
- Page 13 Reading an RFID document (e.g. ePassport): The PENTA Scanner is equipped with two RFID antennas. The two antennas are hidden mounted around the scan window and the sloped part of the housing. Therefore, it doesn’t matter whether the RFID chip is integrated inside the front or rear cover of the passport.
-
Page 14: Service
Please contact our support team, should you require this specific DESKO software package. Warranty Please note that due to improper usage (see chapter 1.2 Handling the DESKO PENTA Scanner) or after opening the device, warranty cannot be claimed anymore. Warranty also excludes normal wear and tear. -
Page 15: Support
Support Please check if the PENTA Scanner is connected and, if needed, the software is installed properly. If this is the case and the device still does not work, please contact our DESKO support team: Technical Support E-mail: support@desko.com Web: www.desko.com/support... -
Page 16: Technical Overview
RF / EMI Compliance: CE and FCC Test report available upon request. Dimensions PENTA Scanner Footprint: 219. 9 mm (8.7 inches) x 150 mm (5.9 inches) x Detailed dimensional drawing is available upon request. 144.7 mm (5.7 inches) // 191.2 mm (7.5 inches) with... -
Page 17: Features Of The Desko Penta Scanner Family
Features of the DESKO PENTA Scanner Family OCR Recognition: OCR reader according to ISO/IEC 7501-1, ISO 18013 and ICAO 9303 ID Document Image Scanning: Scan documents with three different light sources (VIS = 5600 K, IR = 850 nm, UV-A = 365 nm) up to 500... -
Page 18: Regulation Information
(1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. CAUTION: Any changes or modifications not expressly approved by DESKO GmbH could void the user’s authority to operate the equipment. Technical Specification... -
Page 19: Appendix A - Device Mounting Options
Appendix A – Device Mounting Options The PENTA Scanner provides the option to be mounted in different ways. Therefore, the PENTA Scanner is equipped with four thread inserts M3 – depth 4 mm at the bottom side of the device, as indicated in the picture below: You can also purchase the following mounting kits. -
Page 20: Base Mount
Fastening the Wall Mount to a wall and fitting the PENTA Scanner on top will bring you the features of the scanner to every corner. For further information concerning the mounting options, please contact our DESKO support team at support@desko.com or visit our website at www.desko.com/support. -
Page 21: Appendix B - Supplier's Declaration Of Conformity
Appendix B – Supplier's Declaration of Conformity Unique Identifier: PENTA Scanner ® Party issuing Supplier’s Declaration of Conformity DESKO GmbH Gottlieb-Keim-Str. 56 95448 Bayreuth GERMANY Phone: +49 (0)921/79279-0 Web: www.desko.com Responsible Party – U.S. Contact Information DESKO LC 1800 Pembrook Drive...
