Scope This manual describes the MALA HDR series of shielded antenna. It’s a hardware manual, intended to give users a fast guide for handling the antenna units in the field. It’s not a complete system manual. For further information on using the GPR system, please refer to the software manual for the monitor you have bought with the system.
All packing material should be preserved in the event that any damage occurred during shipping. Any claims for shipping damage should be filed to the carrier. Any claims for missing equipment or parts should be filed with MALA GeoScience.
1.2 Repacking and Shipping If original packing materials are unavailable, the equipment should be packed with at least 80 mm of absorbing material. Do not use shredded fibers, paper wood, or wool, as these materials tend to get compacted during shipment and permit the instruments to move around inside the package.
Page 6
compagnies minières à buts lucratifs, les compagnies de construction et les organisations responsables pour le sauvetage et la lutte contre les incendies. Cet instrument répond aux exigences de la licence avec Industrie Canada- exempt des standards RSS. L ‘opération est sujette aux deux conditions suivantes : (1) Cet instrument ne peut pas causer une interférence et (2) cet instrument se doit d’accepter quelque interférence que ce soit, incluant une interférence qui pourrait causer une opération non-souhaitable de l’instrument.
2 External connectors indicators and controls In figure 1, below, pictures of the HDR-160MHz are shown. All antennas in this series have the same basic layout, only that for the 750MHz, no-side handles are available. In the following a brief description of the unit is given, with reference to arrows and labels in figure 1.
2.1 Battery mount In figure 2, below, a dummy battery as well as a normal battery is shown. They look similar but the dummy has a 4-pole fisher connector on the back. The dummy is used when the antenna is powered from an external 12V battery. Both of these units are mounted in the same way on the antenna, see below.
For this reason all MALA cables have ferrites attached to them as well as recommended routing. If you experience some ring-down, please first check your cable mounting, it has been the main cause of internal complaints, previous acceptable routings are no longer valid.
ON/OFF-Switch Figure 6, ON/OFF-Switch 2.5 LED-indicators Three LED-indicators are mounted beneath the product label, see figure 7 below. The meaning of these indicators is as follows: DATA: Continuous flashing light means that the unit is working properly and ready for data collection, no proof of that a monitor is able to receive data, though.
LED-Indicators Figure 7, led indicators. 2.6 Mounting of measuring wheels The several measuring wheels are available for the HDR-units. Each one of them has been designed to fit to the field-proven ruggedized connector housing on the back of the antennas. To connect a wheel, gently push the wheel connector into the connector housing and attach the secure-pin.
Figure 9, a HDR-80MHz mounted in a forest kit, with measureing wheel attached. 4. Software The HDR-antennas can only be operated with MALA XV-monitors; no windows PC software is available. Although a description of the acquisition software is outside the scope of this manual, a brief introduction is give below.
4.1 Projects In order to streamline the data acquisition and provide a user interface optimized in terms of user friendliness, MALA provides application specific data acquisition schemes. In figure 10, below, the first screen (after the start-up info) is shown. The...
In figure 11 below the menu is shown, and in the following a brief description is given. All MALA systems are configured with the most useful and common acquisition parameters when delivered. Hence, the only thing one will have to do form the menu below is to hit the “New”...
Soil velocity: The operator must know this value, if hesitant please refer to tables available in MALA-literature. It does not matter for the actual data acquisition; the only risk is that not deep enough data is gathered. Normal values are 70-120m/us.
Page 16
Point interval: define the distance between every point of measurement, i.e. the distance between every trace. Default values, guarantees no data aliasing. Figure 13, settings menu. Page 16 (16)
