New Mechanism Designs
With auto-stop feature based
on human touch
LP CONNECT
WI-FI BRIDGE
®
Occupancy Detection System
Allows auto-close and other features
based on occupancy status
Customizable Smart
Interface/Buttons
Re-assignable buttons to fit different
Configuration needs
LP Drive Smart Motor Controller
Allows better end-user experience and
custom control of motor
USER GUIDE
LP Drive Motor
Latest technology
Advertisement
Table of Contents
Summary of Contents for Leggett & Platt LP CONNECT
- Page 1 USER GUIDE LP CONNECT WI-FI BRIDGE ® Occupancy Detection System Allows auto-close and other features based on occupancy status Customizable Smart Interface/Buttons Re-assignable buttons to fit different configuration needs New Mechanism Designs With auto-stop feature based on human touch LP Drive Motor...
- Page 2 OVERVIEW The LP Connect Wi-Fi Bridge enables Leggett & Platt’s LP Connect-compatible devices to be connected to a 2.4 GHz wireless network and controlled through software, mobile apps, and automation systems. Because LP Connect uses a bus topology that also carries power, devices can be connected in series, with one power supply and Wi-Fi module servicing several LP Connect devices.
-
Page 3: Network Configuration
“Network Configuration” tab. You can also change the device ID of each of the connected devices using the “CAN Device List” tab. Figure 2. LP Connect configuration website NETWORK CONFIGURATION In the “Network Configuration” tab, you can connect the bridge to a new wireless network and set its IP settings. - Page 4 To refresh the list of connected devices, click “Refresh List.” A list of known connected devices will appear. Devices will not appear in the list if they have not been seen on the LP Connect network for 20 seconds. To change the ID of a device, click on the ID you wish to change and follow the instructions for entering the new ID. The device ID is a number in hexadecimal, and it must be between 0 and 0x3ef (the device IDs between 0x3f0 and 0x3ff are reserved for special features).
