rough country 733.20 Installation Instructions Manual

Thank you for choosing Rough Country for all your suspension needs.
Rough Country recommends a certified technician install this system. In addition to these instructions, professional
knowledge of disassemble/reassembly procedures as well as post installation checks must be known. Attempts to install
this system without this knowledge and expertise may jeopardize the integrity and/or operating safety of the vehicle.
Please read instructions before beginning installation. Check the kit hardware against the product layout on the last page
on these instructions. Be sure you have all needed parts and know where they go. Also please review tools needed list
and make sure you have needed tools.
As a general rule, the taller a vehicle is, the easier it will roll. Seat belts and shoulder harnesses should be worn at all
times. Avoid situations where a side rollover may occur.
Generally, braking performance and capability are decreased when larger/heavier tires and wheels are used. Take this
into consideration while driving. Do not add, alter, or fabricate any factory or after-market parts to increase vehicle height
over the intended height of the Rough Country product purchased. Mixing component brands is not recommended.
Rough Country makes no claims regarding lifting devices and excludes any and all implied claims. We will not be re-
sponsible for any product that is altered.
If question exist we will be happy to answer any questions concerning the design, function, and correct use of our prod-
ucts.
This suspension system was developed using a Maximum tire size
Note if wider tires are used, offset wheels will be required and/or trimming may be required.
Please note that a variation in the rear block and u-bolts exists for this application. 1986-96 short bed standard
cab models require part #s 1733BOX1 & 1734BOX1. All other pickup applications require 1733BOX1 &
1733BOX2. Please verify that the correct box kits are present before beginning the installation process. If you
have any question please call technical assistance at 731-285-9000.
Any vehicle equipped with any Rough Country product should have a "Warning to Driver" decal installed on the inside of
the windshield or on the vehicle's dash. The decal should act as a constant reminder for whoever is operating the vehi-
cle of its unique handling characteristics.
INSTALLING DEALER - it is your responsibility to install the warning decal and forward these installation instructions on
Tools Needed:
22mm Wrench 1/2" Wrench
21mm Wrecnch 7/16" Wrench
12mm Wrench 3/4" Wrench
19mm Wrench 9/16" Wrench
17mm Wrench Hammer
24mm Wrench Floor jack
15mm Wrench Jack stands
13mm Wrench Pry bar
14mm Wrench WD-40 or similar
19mm Wrench penetrating oil
Flat Head Screwdriver
Thread Locker
1986-1996 TOYOTA 4-5" KIT
PRODUCT USE INFORMATION
NOTICE TO DEALER AND VEHICLE OWNER
Torque Specs:
Size Grade 5
5/16" 15 ft/lbs
3/8" 30 ft/lbs
7/16" 45 ft/lbs
1/2" 65 ft/lbs
9/16" 95 ft/lbs
5/8" 135 ft/lbs
3/4" 185 ft/lbs
of
33X12.50 on 8" wheel with 3.75" back spacing.
Class 8.8
6MM
Grade 8
8MM
20 ft/lbs
10MM
35 ft/lbs
12MM
60 ft/lbs
14MM
90 ft/lbs
16MM
130 ft/lbs
18MM
175 ft/lbs
280 ft/lbs
92173300
Class 10.9
5 ft/lbs 9 ft/lbs
18ft/lbs 23 ft/lbs
32ft/lbs 45ft/lbs
55ft/lbs 75ft/lbs
85ft/lbs 120ft/lbs
130ft/lbs 165ft/lbs
170ft/lbs 240ft/lbs
