Summary of Contents for Micron Communications MicroBadge 4053
- Page 1 Users Manual MicroBadge 4053 MICRON COMMUNICATIONS, INC. 3176 South Denver Way; Boise, Idaho 83707-0006 MicroBadge 4053 Users Manual...
- Page 2 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a commercial or residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 3 U S E R S M A N U A L T able of Content S E C T I O N MicroBadge 4053 Reader Description S E C T I O N Installation Instructions S E C T I O N...
- Page 4 Section MicroBadge 4053 Reader Description The MicroBadge 4053 RFID reader is a self-contained low frequency reader for powering and interrogating passive RFID transponders. The reader is configured to interface with other electronic devices via an RS-232 or RS-485 connection. The 4053 reader emits a low frequency magnetic field, which will provide enough energy to power a transponder within the read range of the transponder.
- Page 5 Section Installation Instructions The reader should be mounted near the location that is desired to be monitored. Before final installation of the reader, test the system with tags at range and orientation typical of system operation. Typically, the read range for a credit card size transponder is approximately 8 inches, and an 18mm button transponder has a read range of 5 inches.
- Page 6 If an audible “beep” is not heard, verify that the LED is glowing RED, which indicates that power is being supplied to the reader. Try another transponder, and bring it closer to the reader antenna. If this fails to produce a sound, disconnect the unit from the computer and from power and call the factory.
- Page 7 Section Operating Limitations Storage Temperature Degrees C Operating Temperature Degrees C Operating Frequency 127 KHz Read Range Power Consumption Watts Power Supply Voltage 15.0 VDC...
- Page 8 Section Maintenance There are no user repairable components within the reader, and any maintenance performed on the reader should be performed only by factory trained personnel.
