IMPORTANT INSTRUCTIONS
PLEASE READ THIS MANUAL BEFORE INSTALLING AND USING APPLIANCE
WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOL-
LOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING
PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
WARNING: THIS PRODUCT IS ONLY FOR USE WITH MODELS SPECI-
FIED IN THIS MANUAL BY THE MANFACTURER. ANY OTHER USAGE OR
INSTALLATION NOT SPECIFIED IN THIS MANUAL IS PROHIBITED.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Questions, problems, missing parts? Before returning to your retailer,
call our customer service department at 1-888-256-6465 during normal
business hours.
Wall Heater Fan
This fan is a CSA approved component compatible
with these Williams wall heaters only
1
MODEL #: 2275
1076512.9
2076512.9
3076512.9
1076511.9
2076511.9
3076511.9
1076542.9
2076542.9
3076542.9
1076541.9
2076541.9
3076541.9
IMWHFWL - 2016-06-15
:
1276512
1876512
3076512
1276511
1876511
3076511
1276542
1876542
3076542
1276541
1876541
3076541
Advertisement
Table of Contents
Summary of Contents for Williams 2275
-
Page 1: Important Instructions
Wall Heater Fan MODEL #: 2275 This fan is a CSA approved component compatible with these Williams wall heaters only 1076512.9 2076512.9 3076512.9 1276512 1876512 3076512 1076511.9 2076511.9 3076511.9 1276511 1876511 3076511 1076542.9 2076542.9 3076542.9 1276542 1876542 3076542 1076541.9 2076541.9 3076541.9... - Page 3 SAFETY INFORMATION SAVE THESE INSTRUCTIONS IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, operate,or service this heater. Improper use of this heater can cause serious injury or death from burns, fire,explosion, electrical shock, and carbon monoxide poisoning. WARNING: Electrical Grounding Instructions This appliance is equipped with a three-prong (grounding) plug for your protec- tion against shock hazard and must be plugged directly into a properly grounded...
- Page 4 ASSEMBLY INSTRUCTIONS Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and diagram under. If any part is missing or dam- aged, do not attempt to assemble, install or operate the product. Contact custom- er service for replacement parts at 1-888-256-6465.
- Page 5 OPERATING INSTRUCTIONS This fan is equipped with manual “MAN” and auto- matic “AUTO” settings. Set the rocker switch to “MAN” for manual mode, allowing the fan to continuously run until the rocker switch is returned to the OFF “O” posi- tion.
-
Page 6: Troubleshooting
MAINTENANCE OF MOTORS WARNING: Make sure all power to the appliance is turned OFF before proceeding. Always disconnect the appliance from the main power supply and allow it to cool before any servicing operation. The motor used on the fan is pre-lubricated for extended bearing life and requires no further lubrication. -
Page 7: Installation Record
Warranty & Installation Record – 2 Warranty The Manufacturer, Williams Furnace Co., warrants this wall heater or heater to the original purchaser under the following conditions: LIMITED ONE-YEAR WARRANTY 1. Any part thereof which proves to be defective in material or workmanship within one year from date of original purchase for use will be repaired or replaced at the Manufacturer’s option, FOB, its factory.
