INCLUDED IN THE PACKAGE
BUTTONS AND PARTS
A. Emergency
B. PTT1
C. PTT2
D. Loophole
AINA PTT Smart Button
USER GUIDE
DOC ID : IU0006 ver. 1.2
+
X 1
X 1
CR2032
E. Button cell battery
cover
F. NFC tag location
AINA Wireless

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PTT Smart Button and is the answer not in the manual?

Questions and answers

Related Manuals for AINA PTT Smart Button

Summary of Contents for AINA PTT Smart Button

  • Page 1 AINA PTT Smart Button USER GUIDE AINA Wireless DOC ID : IU0006 ver. 1.2 INCLUDED IN THE PACKAGE CR2032 BUTTONS AND PARTS A. Emergency E. Button cell battery cover B. PTT1 F. NFC tag location C. PTT2 D. Loophole...
  • Page 2 INSERTING THE BUTTON CELL BATTERY (1) CR2032 CR2032...
  • Page 3 INSERTING THE BUTTON CELL BATTERY (2) 1. Unscrew the button cell battery cover anticlockwise with a tool or coin until it pops up 2. Remove the cover and insert the button cell battery 3. Put the cover back on top 4. Gently push down the cover and screw it clockwise to secure it into place.

  • Page 4: Power On/Off

    POWER ON / OFF CR2032 CR2032 When the button cell battery is inside, the device will be constantly ON. To turn the device OFF, you must remove the battery. Wenn die Knopfzellen-Batterie eingelegt ist, bleibt das Gerät konstant EINgeschaltet. Um das Gerät AUSzuschalten, müssen Sie die Batterie entfernen.
  • Page 5 PAIRING (1) 3 sec 1. Press all three buttons simultaneously for 3 seconds to put the device into pairing mode (and remove any previous pairings) 2. Make sure that your phone’s NFC feature is turned on 3. Make the phone and device touch so that the NFC tag on the Smart Button comes as close as possible to the NFC reader on the phone.
  • Page 6 PAIRING (2) 1. Appuyez simultanément sur tous les trois boutons pendant 3 secondes afin de mettre le dispositif en mode couplage (et de supprimer tous les couplages précédents) 2. Assurez- vous que la fonction NFC de votre téléphone est bien activée 3. Établissez un contact physique entre le téléphone et le dispositif afin que l'étiquette NFC de Smart Button se trouve le plus près possible du lecteur NFC du téléphone.

  • Page 7: Additional Safety Tips

    Operating frequency range: 2400 - 2483.5MHz Bluetooth power level: Class 2 (Smart 2.5mW) OPERATION For more detailed instructions on setting up and using your PTT Smart Button, please visit www.aina-wireless.com CUSTOMER CARE If any part of the equipment is damaged on arrival, contact the shipper to conduct an inspection and prepare a damage report.

  • Page 8: Garantie Registrierung

    GARANTIE REGISTRIERUNG Bitte registrieren Sie dieses Produkt innerhalb von 10 Tagen nach dem Kauf. Durch die Registrier- ung wird die Garantie bestätigt. Außerdem ermöglichen Sie AINA Wireless so, Sie hinsichtlich eventueller Sicherheitsmeldungen zum Produkt zu kontaktieren. Registrieren Sie Ihr Produkt online unter: www.aina-wireless.com...

  • Page 9: Opération

    ENREGISTREMENT DE LA GARANTIE Veuillez enregistrer ce produit dans les 10 jours suivant l'achat. L'enregistrement valide la ga- rantie et permet à AINA Wireless de vous contacter en cas de notification de sécurité relative à ce produit. Veuillez effectuer l'enregistrement en ligne sur www.aina-wireless.com...

  • Page 10: Operación

    Por favor registre este producto dentro de 10 días de su compra. El registro validará la cobertura de la garantía y permitirá a AINA Wireless ponerse en contacto con usted en caso de cualquier notificación de seguridad emitida para este producto.
  • Page 11 REGULATORY FCC Part 15 15.21 Warning: Changes or modifications to this equipment not expressly approved by the party re- sponsible for compliance could void the user’s authority to operate the equipment. 15.105(b) Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
  • Page 12 This device complies with part 15 of the FCC Rules. Operation is subject to following two condi- tions: This device may not cause harmful interference, and this device must accept any interference received, including interference that may cause undesired operation. FCC RF Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
