Summary of Contents for XtendLan XL-HB192M
- Page 1 XL-HB192M HPNA3 over Phoneline Ethernet Bridge User’s Guide...
- Page 2 INTRODUCTION This HomePNA to Ethernet bridge connects any Ethernet device to a high speed access device or to a Home Networking LAN for Internet access. This bridge brings you the newest Ethernet compatible technology that uses the telephone wiring as the network's physical wiring thereby eliminating the need to install new wiring.
-
Page 3: Hardware Installation
HARDWARE INSTALLATION Parts Names and Functions LED Indicators on the Rear Panel Status Port Flashing Powered by DC IN Not powered DC 5 ~ 12V Receive Disconnect Link LAN1 Link Transmit Link fail Receive Disconnect Link LAN2 Link Transmit Link fail Link Receive Link... - Page 4 Ports on the Rear Panel Type Functions Port Name Connects to the power adapter plug. DC IN Connects to Ethernet port on LAN1 / LAN2 RJ-45 FTTH/xDSL Modem, Switch/HUB, (Ethernet) PC and STB for Internet Access. RJ-11 Connect to Phone Phone RJ-11 Connect to other HPNA devices HPNA...
- Page 5 CAT5 Connects from Ethernet port cable Ethernet enabled devices as or STB DC5~12V Connects from Power Power port of adapter main unit into a wall outlet Additional Items Description (Not included) A well-installed WAN environment (Cable Modem or xDSL Modem) A well-installed LAN environment - 4 -...
- Page 6 Hardware Connections 1. Select a convenient location for the bridge near the PC or Ethernet device to which it will be connected. The bridge should be kept away from excessive heat. 2. Using one telephone wire to connect the HPNA port to RJ-11 jack on the wall.
- Page 7 The figure above shows how to connect a cable modem to a home phoneline network. Follow the same steps to connect any Ethernet device such as a STB or PC, to a home phoneline network. After properly connected the LAN port, HPNA port and the DC IN port, LED will be as: LAN Link/Act HPNA Link/Act...
-
Page 8: Troubleshooting
TROUBLESHOOTING The bridge has been designed to be a reliable and easy to use connection device. Please refer to the list below to aid in troubleshooting. The Power (green PWR) LED is off. ƒ Make sure the power adapter is properly plugged into a live electrical outlet. -
Page 9: Specifications
SPECIFICATIONS Standards IEEE 802.3 10BaseT Ethernet compliant IEEE 802.3u 100BaseT Fast Ethernet compliant HomePNA 3.1 specifications compliant Data Rates HPNA: 192Mbps (36 - 68MHz) 224Mbps (12 - 44MHz ) 128Mbps (12 - 28MHz) Ethernet: 10/100 Mbps Power Consumption 5~12V DC IN, less than 3 watt Certifications CE, FCC Part 15 LEDs...
