Spirent TestCenter Live 4150 Installation Manuals

Spirent TestCenter Live
LOCATE ALL REQUIRED CABLES
1.
You should have;
1 x Ethernet cable

1 x AC Power Adaptor

2. MOUNT UNIT TO THE WALL
the (optional) mounting
bracket supplied.
3. ATTACH ANTENNA
Screw in until finger-tight.
4. CONNECT ETHERNET CABLE
Connect the Ethernet cable from the
unit to a DHCP-enabled network
which allows public internet access.
NOTE: Not providing Ethernet
connectivity will result in limited fault
isolation in the event of a network or
probe failure
5. INSERT USB FLASH DRIVE
This contains the CONFIG File used to
boot-up the probe.
6. CONNECT POWER CABLE
Plug the Power Cable into the DC 5V port.
Note: Ensure the USB flash drive is inserted before powering up the
device, and your smartphone is ready to receive the BLUETOOTH
confirmation messages.
Also If using an Ethernet cable make sure it is plugged in before adding
power.
4150 Installation Guide
Use
(USB flash drive not included)
DC5V
From AC Power Adaptor
