AOB 5B532BT User Manual

5B532BT is a multi-function Bluetooth MP3, which can play MP3 with Bluetooth, sub
drive and TF card, with microphone and LINE IN function.
一、Safety precautions
1.Keep away from children.
2.Non-original factory accessories and accessories do not have warranty
qualification.
3.Users cannot disassemble themselves. If there is any failure, please contact the
supplier.
4.Charging must be done in a well-ventilated environment, away from
inflammable and explosive materials.
5.Avoid exposure to strong sunlight or high humidity.
6.Avoid falls, collisions, and excessive extrusion, otherwise you will suffer different
degrees of damage.
二、List of specifications
1、Size: 74.55 * 72.45 * 80.7mm
2、Weight (g) : 116.0 plus or minus 10g
3、Applicable voltage: DC 3.7 ~ 4.2v
4、Charging voltage: DC 5V
5、Battery specification :50 30 40 400mA
6、Loudspeaker specification: diameter 40mmm
internal magnetic horn
7、Charging interface: DC power socket
8、LINEIN interface: 3.5mm headphone stand
5B532BT User manual
10、Bluetooth version: Vesion 2.1
11 、 Bluetooth frequency band: 2.402 ~
2.480GHz
12、Bluetooth RANGE: >10M
13、Amplifier type AB/D type mono channel
14、Audio format supported: MP3
15、FM receive band: 87.5-108.0MHz
16、
17、Signal-to-noise ratio: 80db
- 1 -
Playback time: 1 hour
