Easywave RTRP02 series Operating Instruction

Plug-In Radio Alarm Annunciator RTRP02
GB

Models

Battery control
notice
Button 0/LED 0
OFF
Schuko
D/A/NL/S/N GB F/B/PL
RTRP02E5001 -01 868.30 MHz
RTRP02E5001-02 868.30 MHz
RTRP02E5001-04 868.30 MHz
RTRP02E5001-05 868.30 MHz

Technical Details

Frequency: 868.30 MHz
Modulation: FSK
Channel: 1x receive
Range: up to 150 m under
favourable open field
conditions
Operating voltage: 230 V AC / 50 Hz
Current consumption
- real power: max. 0.6 W
- apparent power: max. 1.8 VA
Degree protection:IP 20
of
Operating
temperature: -20°C to +35°C
Max. relative air
humidity: 60%
Mains output: Power plug
Max. contact load: 10 A / 230 V AC
Dimensions 122 x 50 x 38.3 mm
:
(HxWxD)
Weight: approx. 190 g
SPL: 85 dB / distance 30 cm

Scope of Delivery

Alarm annunciator RTRP02, Operating
instruction
Safety A dvice
Wall outlet
We do not accept any liability for personal
injury or damage to property caused by
incorrect handling or non-observance of the
safety instructions!
Keep the Alarm annunciator away from
children!
Attention! Observe the admissible supply
Loudspeaker
voltage and the maximum contact load of the
wall outlet (10 A, 230 V AC / 50 Hz)!
Do not plug one Alarm Annunciator into
another.
The device is only de-energized when it is
Button 1/LED 1
disconnected from the mains supply.
ON
The device must be easily accessible.
Observe the valid laws and regulations as well
as the manufacturer's instructions
devices to be operated.
Have malfunctioning devices checked by the
manufacturers!
Do not open the appliance's casing!
Do not make any unauthorized alterations or
modifications to the device!

Concept of Operations

CH
Function/Chapter
D
GB
Memorizing a
Window handle
F/B
contact RTS26
CH
Memorizing an
acknowledgement
transmitter
Switch on
2x transmit
/
alarm function
Switch off
alarm function
Acknowledge the
alarm
Switch On Lighting
(Transmission
code A1 (ON)
transfer)
( non switchable )
Close A Shutter
(Transmission
code B2 (DOWN)
transfer)
Reset to Default
Settings (RESET)
Undervoltage
message window
handle contact
Carefully read through these
instructions before using the
device.
for the
Operation
[press the button]
1. button 0 + button 1 >1,6 s
button 0
2. button RTS26
1. button 0 + button 1 >1,6 s
button 0
2. button 1 >1,6 s
button 0
3.
button acknowledgement trans.
button 1 >1,6 s
button 0 >1,6 s
button 0 oder button 1
or
button acknowledgement transm.
1. button 0 + button 1 >1,6 s
button 0
2. button 1 >1,6 s
button 0
3. button 1
1. button 0 + button 1 >1,6 s
button 0
2. button 0 >1,6 s
3. button 0
1. button 0 + button 1 >1,6 s
button 0
2. button 0 + button 1 >1,6 s
acknowledge with
button 0 oder button 1
Intended Use
The alarm indicator RTRP02 may only be used in
dry indoor rooms as acoustic signalling device for
alarm messages and messages concerning the
battery status of the window handle contact
RTS26 (evaluation of undervoltage diagram).
The outlet can only be used for mains voltage
consumers (10 A, 230 V AC, 50 Hz).
The manufacturer will not be liable for damage
caused by improper or inappropriate use.
Function
The alarm indicator RTRP02 is a wireless
receiver that reports manipulations to the window
handle by emitting an acoustic signal in
connection with an activated wireless window
handle contact RTS26.
Altogether 32 window handle contacts can be
monitored by the alarm indicator.
It is also possible to evaluate an undervoltage
telegram indicating the low battery status of a
window handle contact.
The low battery status is signalled with a blinking
battery status display and can be deactivated by
pressing the button 1 or 0 on the alarm indicator.
This function is also available when the alarm
indicator is deactivated.
LED-view RTRP02 Result
LED 0 + LED 1 flashes after 20 s operation mode
break
LED 1 lights up 3 s afterwards operation mode
LED 0 + LED 1 flash after 20 s operation mode
break
LED 1 flashes after 20 s operation mode
break
LED 1 lights up 3 s afterwards operation mode
LED 0 + LED 1 light up Alarm annunciator activates
LED 0 + LED 1 out Alarm annunciator deactivates
Further alarm messages are
possible after 5 minutes.
LED 0 + LED 1 flash after 20 s operation mode
break
LED 1 flashes after 20 s operation mode
break
LED 1 lights up 3 s Send code A1 is sent for 3 s,
afterwards operation mode
LED 0 + LED 1 flash after 20 s operation mode
break
LED 0 flashes after 20 s operation mode
LED 0 flashes 3 s Send code B2 is sent for 3 s,
afterwards operation mode
LED 0 + LED 1 flash after 20 s operation mode
break
LED 0 LED 1 light up 3 s dann operation mode
+
battery control notice change the battery of the
window handle contact
flashes
