Eglo 96452 Instruction Manual

96452/96454
Infrared Motion Sensor
Instruction Manual
3
96452_96454_bda.indd 1
96452/96454
OPEN
2
1
L' N L
Welcome to use 96452/96454 infrared motion sensor!
The product adopts good sensitivity detector and integrated circuit. It combines automation,
convenience, safety, energy-efficience and practical functions. It utilizes the infrared energy from
humans as control-signal source and it can start the load at once when one enters the detection
field. It can identify day and night automatically. It is easy to install and used widely.

SPECIFICATION:

Power Source: 220-240V/AC
Power Frequency: 50/60Hz
Ambient Light: <3-2000LUX (adjustable)
Time Delay: Min.10sec±3sec
Max.15min±2min
Rated Load: Max.1200W
300W

FUNCTION:

• Can identify day and night: The consumer can adjust working state in different ambient light. It
can work in the daytime and at night when it is adjusted on the "sun" position (max). It can work
in the ambient light less than 3LUX when it is adjusted on the "3" position (min). As for the ad-
justment pattern, please refer to the testing pattern.
• Time-Delay is added continually: When it receives the second induction signals within the first
induction, it will restart to time from that moment.
Good sensitivity

INSTALLATION ADVICE:

Since the detector responds to changes in temperature, avoid the following situations:
• Avoid pointing the detector towards objects with highly reflective surfaces, such as mirrors etc.
• Avoid mounting the detector near heat sources, such as heating vents, air conditioning units,
light etc.
• Avoid pointing the detector towards objects that may move in the wind, such as curtains, tall
plants etc.
Detection Range: 180°
Detection Distance: 12m max(<24C°)
Working Temperature: -20~+40C°
Working Humidity: <93%RH
Power Consumption: approx 0.5W
Installation Height: 1.8-2.5m
Detection Moving Speed: 0.6-1.5m/s
Poor sensitivity
