USER MANUAL VICTOR 230
Electronic ioniser – Indoor air purifier
Attention! Do not touch needle when unit is turned on!
Function:
By combination of three of the world's most recognized technologies of
VICTOR 230 is able to achieve comprehensive purification: dust purification, removal of bacteria and
elimination of unpleasant odours. All that can be achieved by means of a very powerful generator of
ions. It produces negatively charged ions that are able to remove suspended particles from the air and
thus purify the air. Active oxygen is in the position to destroy bacteria, viruses and mites. The power
consumption for the mechanics of filtration, purification and for the fan is 14 W only.
Bond of dust:
After a few days of use, you will find a considerable deposit of air pollutants on the different filter
systems (such as metal plates) and on the „PLASMA DUST COLLECTOR". Those filter systems purify
the air in the interior of the
smaller than 0.1 μm). The ionisation wires ensure an enrichment of negatively charged ions in the local air.
Well-being effect:
VICTOR 230 removes dust, odours and bacteria within a minimum of time and supports
AIRBUTLER
well feeling in general. You can breath fresh and pleasant air.
VICTOR 230
AIRBUTLER
PARKER 120 (by eliminating dirt particles and bacteria even
purification,AIRBUTLER
Advertisement
Table of Contents
Related Manuals for Airbutler VICTOR 230
Summary of Contents for Airbutler VICTOR 230
- Page 1 By combination of three of the world’s most recognized technologies of purification,AIRBUTLER VICTOR 230 is able to achieve comprehensive purification: dust purification, removal of bacteria and elimination of unpleasant odours. All that can be achieved by means of a very powerful generator of ions.
-
Page 2: Instructions For Operation
INSTRUCTIONS FOR OPERATION Locate the appliance on a solid surface. Be sure the grille is not blocked by other objects and that there are no candles or flames near the unit. Before plugging in the unit, please open the windows in the area where you will be using the unit. Ventilate the area for 2-3 hours if possible. -
Page 3: Control Panel Instructions
CONTROL PANEL INSTRUCTIONS A) ON/ OFF BUTTON BUTTON A By pressing once, you can switch on the unit and the display screen will illuminate. The appliance AUTO MODE will start to operate under . By pressing it twice, the unit is switched off. B) AUTO MODE / FAN SPEED BUTTON B AUTO MODE... - Page 4 F) CLEANING INDICATOR “CLEAN CELL” If red indicator appears on the display, the appliance should be cleaned as recommended by the manufacturer. When the collector cell is re-installed after cleaning, switch on the appliance BUTTON E and keep pressing the at least 3 seconds until buz- “CLEAN CELL”...
-
Page 5: Cleaning And Maintenance
CLEANING AND MAINTENANCE CLEANING “CLEAN CELL” “CLEAN When the red indicator is blinking, please restart your appliance. If the red CELL” “CLEAN CELL” indicator is still blinking, please clean your collector cell. When the red indicator illu- minates or collector cell is too dirty or if snapping sounds become frequent, please clean your collector cell. Proper care and cleaning of the air purifier is critical to performance. - Page 6 CAUTION! The collector cell may not require cleaning if “arcing” occurs. Arcing is a sharp snapping sound that occurs when large particles are collected in the collector cell or the appliance used in overdamp rooms. If prolonged or continuous arcing occurs, the collector cell should be cleaned. CLEANING THE COLLECTOR CELL 1.
- Page 7 CLEAN CELL INDICATOR IS BLINKING The collector cell must be completely dry after cleaning in order to operate properly. In case the residual water left “CLEAN CELL” in the collector cell gap, the red indicator will blink rapidly once operation. In this case, please re-dry the collector cell under the sunlight, and then “CLEAN CELL”...
-
Page 8: Troubleshooting
TROUBLESHOOTING Service problems that appear to be major can often be solved easily. You can be your own troubleshooter by reviewing this guide. All other servicing should be done by a local authorized service center. PROBLEM CHECK SOLUTION Appliance does Power cord Plug in power cord not turn ON... -
Page 9: Specifications
SPECIFICATIONS High performance DC fan, low energy consumption, durable use. Night operating mode, quiet and comforting. Built-in smart sensor, automatic sensing and adjust airflow speed, intelligent operation. Plasma electrostatic dust collector, easy to clean, never needs to be replaced. Large volumes of air rapidly circulate and purify air. High performance filter effectively removes extra fine particles of 0.1 - 0.3 microns. - Page 10 Do not use the appliance in an enclosed space where flammable, combustible or explosive gases are present. Do not use in an area where toxic vapours, flammable dust or oxygen tanks are present. Check the location and make sure these elements are not present. This equipment should be inspected frequently and the dirt that has collected should be removed regularly to prevent excessive accumulation that may result in flashover or fire.
-
Page 11: Warranty
WARRANTY AIRBUTLER products are subjected to stringent testing before they leave the factory. Guarantee of function for two years from date of purchase. Damage and malfunctions within the warranty period are only dealt with on presentation of the completed warranty certificate. Please return the appliance to the trader so that the cause of malfunction can be identified. - Page 12 SPECIFICATIONS VICTOR 230 Model AP-C230A Related Voltage AC 240V/50~60Hz Power 14 W Activated Oxygen Output ≤ 0.05 ppm Noise (max) 61db(A) CADR Value 180m Dimensions 362 x 231 x 495 mm Net Weight 8.5 kg Room Size 20~40m...
