- Page 1 TECHLUX MONITOR HEADREST TL097002 User’s Manual Please read the manual carefully before use and keep it Safe for your future reference. V20080116...
- Page 2 Important safety instructions: Precautions: For your safety do not turn on watch or operate the unit while driving. In some countries and regions it may be against the law. The product is comprised of many precision electronic components, self-renovation or disassembling may cause malfunction to the device.
-
Page 3: Table Of Contents
Content Features............................3 Precaution............................3 Brief Instructions ..........................3 Accessories ..........................3 Instructions for Remote control ....................3 Installation and connection Method ....................4 Sketch map of the remote control ....................4 Sketch map of the monitor ......................5 Funtions explanation (Monitor version 1)...................6 Functions explanation (Monitor version 2).................7 Trouble Shooting ..........................8... -
Page 4: Features
Features Easy Installation, Non hazardous design Adjusting Headrest pole spacing between 125mm to 165mm, to meet installing requirements of many seats. Diameter of the headrest poles are available for 10mm, 12mm and 14mm Two monitors unit with 7” wide screen Dual AV Input. -
Page 5: Installation And Connection Method
Push Pull Installation and connection Method Please make sure of the suitability of the system. Use suitable accessories and tools in installation or disassembling. Installation Methods: Step 1 Removing the original Headrest Step 2 Selecting the right headrest poles and installing the monitor then adjusting the poles into the right position Step 3 Threading the power cord and the A&V cord through the steel tubes on the backside of the seat... -
Page 6: Sketch Map Of The Monitor
Sketch map of the monitor AUDIO/VIDEO INPUT AUDIO/VIDEO INPUT +12V POWER SUPPLY... -
Page 7: Funtions Explanation (Monitor Version 1)
Funtions explanation (Monitor version 1) 1- IR TRANSMITTER (Headphone) Infra Red transmitter allow to use IR Headphone. Use Mode/Select button on remote control to switch between IR channels (A and B channels are available) 2- POWER Press Power button to power ON/OFF the monitor. 3- VIDEO1 Press V1 button to select the video 1 input Press Video/Select button on remote control to switch between video 1 and 2 inputs... -
Page 8: Functions Explanation (Monitor Version 2)
Functions explanation (Monitor version 2) 1- IR TRANSMITTER (Headphone) Infra Red transmitter allow to use IR Headphone. A and B channels are available (see Menu settings for details) 2- POWER Press Power button to power ON/OFF the monitor. 3- VIDEO1 Press V1 button to select the video 1 input Press Video/Select button on remote control to switch between video 1 and 2 inputs 4- VIDEO2... -
Page 9: Trouble Shooting
Trouble Shooting ● No Sound or bad sound Please check if cables are connected properly ● No Picture Check if cables are connected properly. Check the monitor is on or off. ●Poor picture The color is not properly adjusted; please use the remote control to adjust it. ●The remote control does not work properly There is an obstacle in the path of the remote control and the unit. -
Page 10: Warranty Terms And Conditions
8) For repairs: Please contact your retailer. 9) For any disputes or litigation: The law courts of Luxembourg are exclusively competent. 10) For all information: Contact: TECH LUX Zone Industrielle Breedewues L-1259 Senningerberg LUXEMBOURG Phone: (+352) 26 34 57 29 Fax: (+352) 26 34 57 27 Email : svc@sevic.com...
