87001
JEEP CJ5, CJ7 & SCRAMBLER
MAX TRAILER WEIGHT
Bolt Size
Grade 5 Torque
3/8
30 Ft. Lb.
7/16
54 Ft. Lb.
1/2
72 Ft. Lb.
5/8
150 Ft. Lb.
3/4
245 Ft. Lb.
Maximum torque for tab nuts is 38 Ft. Lb.
Warning:
This hitch is designed to safely carry the loads specified. Under no circumstances do we recommend exceeding the towing
vehicle manufacturer's recommended vehicle towing capacties.
®
3500 lbs.
MAX TONGUE WEIGHT
Metric
8 mm
10 mm
12 mm
14 mm
300 lbs.
Grade 8.8 Torque
18 Ft. Lb.
36 Ft. Lb.
64 Ft. Lb.
103 Ft. Lb.
Advertisement
Table of Contents
Summary of Contents for Hidden Hitch 87001
- Page 1 87001 JEEP CJ5, CJ7 & SCRAMBLER ® MAX TRAILER WEIGHT 3500 lbs. MAX TONGUE WEIGHT 300 lbs. Bolt Size Grade 5 Torque Metric Grade 8.8 Torque 30 Ft. Lb. 8 mm 18 Ft. Lb. 7/16 54 Ft. Lb. 10 mm 36 Ft.
- Page 2 5. Tighten all bolts; refer to the torque table on the instruction sheet. 5. Use carriage bolts (4) and flange nuts (3) to attach flat brackets to the frame. 6. Tighten all bolts; refer to the torque table on the instruction sheet. HIDDEN HITCH TOW HOOKS HITCH MOUNTS...
