F.W. Bell 4080 Operating Instructions

SPECIFICATIONS
M e a s u r e m e n t 0 . 1 - 5 1 1 m G ( s t d . )
0 . 0 1 - 5 1 . 1 µ T ( o p t . )
R a n g e
A c c u r a c y
E r r o r
± ( 2 % o f r d g . +
( t y p i c a l )
> 4 m G
1 d i g i t )
± ( 1 d i g i t )
< 4 m G
± 1 % , t y p .
D i r e c t i o n a l i t y
± 3 % , m a x .
E r r o r
O v e r a l l E r r o r
± 5 % o f r d g . , m a x .
> 4 m G
± 2 d i g i t , m a x .
< 4 m G
F r e q u e n c y 2 5 H z - 1 k H z
R e s p o n s e
C a l i b r a t i o n 6 0 H z
F r e q u e n c y ( 5 0 H z o p t . )
D i s p l a y 3 d i g i t L C D
M e a s u r e m e n t T r u e R M S
T y p e
S a m p l i n g 0 . 4 s e c .
I n t e r v a l
B a t t e r y L i f e 4 0 h o u r s ( t y p . )
P o w e r 9 V a l k a l i n e
S o u r c e b a t t e r y
0 ° t o + 5 0 ° C
O p e r a t i n g
T e m p
W e i g h t 5 o z .
S i z e 4 . 7 " L x 2 . 4 " W x
1 . 0 " D
W a r r a n t y O n e Y e a r
