STI Engineering RFI-148 User Manual

High output power paging transmitters
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Rhein Tech Laboratories, Inc.
Client: STI Engineering
360 Herndon Parkway
Model: RFI-900 250
Suite 1400
FCC ID: P5MRFI900
Herndon, VA20170
Standards: FCC Part 90
http://www.rheintech.com
Report #: 2018010
Appendix J:
Manual
Please refer to the following pages.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RFI-148 and is the answer not in the manual?

Questions and answers

Summary of Contents for STI Engineering RFI-148

  • Page 1 Rhein Tech Laboratories, Inc. Client: STI Engineering 360 Herndon Parkway Model: RFI-900 250 Suite 1400 FCC ID: P5MRFI900 Herndon, VA20170 Standards: FCC Part 90 http://www.rheintech.com Report #: 2018010 Appendix J: Manual Please refer to the following pages.
  • Page 2 RFI-148 & RFI-900 HIGH OUTPUT POWER PAGING TRANSMITTERS USER MANUAL...
  • Page 3 DISCLAIMER © 2018 STI Engineering Pty Ltd. All rights reserved. STI Engineering reserves the right to make improvements on the product in this manual at any time without notice. No part of this manual may be produced, copied, translated, or transmitted in any form or by any means without the written permission of STI Engineering.

  • Page 4: Table Of Contents

    4.3.6 RF Diagnostics ................................26 4.4 Data ......................................26 4.4.1 4-Level Deviation Mapping ............................26 4.4.2 Carrier Offset .................................. 27 4.4.3 Custom Deviation ................................27 4.5 Fan Control .................................... 27 RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 3 of 99...
  • Page 5 B.2 Glenayre C2000 Controller / FLEX Mode ..........................48 B.3 Glenayre C2000 Controller / POCSAG Mode ........................48 B.4 Zetron Model 66 Transmitter Controller / POCSAG Mode ....................49 RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 4 of 99...
  • Page 6 G.3.1 PTT Override ................................. 96 G.3.2 Hardware or Auto PTT ..............................97 G.3.3 Profile Definition ................................97 G.4 Unit Transmits at Low Power ..............................97 Appendix H Glossary ..................................98 RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 5 of 99...

  • Page 7: Introduction

    Appendix A Technical Specifications 1. Introduction The RFI-148 and RFI-900 are high power output paging transmitters operating in the VHF and UHF band, respectively. RFI-148: VHF band operation (138 MHz –  174 MHz) with 2.5 MHz switching bandwidth RFI-900: UHF band operation (929 MHz –...

  • Page 8: Installation

    Nearby lightning strikes or high levels of static electricity may lead to interface failure. The Ethernet cable from the RFI-148/900250 to the Ethernet switch must be less than 10 metres long. STI Engineering supplies a range of external data interface converters for applications requiring long cable runs.

  • Page 9: Product Installation

    Ethernet: Ethernet connection for configuration and diagnostics over UDP. RJ45 connector. The Ethernet cable from the RFI-148/900250 to the Ethernet switch must be less than 10 metres long. AC Switch: Power switch. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual...

  • Page 10: Installation Guidelines To Ensure Safe Exposure Levels

    Connect other cabling, leaving power cables last. Ensure that the safe distance limits in are met before powering and operating the unit, using Table 1 physical exclusion barriers if necessary. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 9 of 99...

  • Page 11: Typical Installation

    In a typical installation the RFI-148/900 250 will be housed in a weather-proof structure. Inside the weather- proof structure a 2 m EUPEN 5092-HLFR cable will connect the antenna port of the RFI-148/900 250 to the input of a band-pass cavity filter (CV1417-0111-11 for RFI-148 or CV9296-0511-11 for RFI-900) . A 5 m...
  • Page 12 High rise building distance > 40 m Antenna Weather-proof height ≈ structure containing 30 m RFI-148/900 250 paging transmitter Installation is completely fenced off. Figure 3: Typical installation site RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 11 of 99...

  • Page 13: Safety And Compliance

    The installation should be in accordance with EN 50310:2010. 2.4.3 Modifications CAUTION: Changes or modifications not expressly approved by STI Engineering will void the user’s authority to operate the equipment legally, as well as any warranty provided. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual...

  • Page 14: Configuration

    This section outlines how to use Cruise Control with the paging transmitter. For more information see the Cruise Control User Manual. Figure 4 below is a screenshot of Cruise Control running on Windows 10. Figure 4: Cruise Control Interface RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 13 of 99...

  • Page 15: Installation

    Cruise Control can provide real-time operational information for paging transmitters using the Sensor Gauges plugin. A screenshot of the Sensor Gauges plugin is shown below in Figure 5. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 14 of 99...

  • Page 16: Firmware Update

    Cruise Control supports the updating of device firmware. Cruise Control will only allow firmware images that are compatible with the paging transmitter to be uploaded. For more information, see section 0. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 15 of 99...

  • Page 17: Snmp

    RFI SNMP Proxy is compatible with standard SNMP managers and other SNMP client applications. An SMI MIB file defining OIDs for this product is available from STI Engineering. RFI SNMP Proxy communicates with the paging transmitter via a proprietary protocol using UDP port 64252 through the Ethernet interface.

  • Page 18: Terminal Menu Interface

    AT command. A terminator can consist of a carriage return (ASCII value 13 ) or a carriage return followed by a line feed (ASCII value 10 Decimal Decimal RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 17 of 99...

  • Page 19: List Slicing Syntax

    For example, the AT commands for the serial number, current channel, and main serial port baud rate are I6, S54 and S100[0], respectively. These commands can be run separately: RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 18 of 99...

  • Page 20: Front Panel Interface

    Power Turns on/off at 1 Hz while power is supplied. Power Gauge Green/Red A bar graph displaying current transmit power. Table 3: Front panel LED descriptions RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 19 of 99...

  • Page 21: Liu Interface

    The use of the transmit clock is optional for 2-level protocols, but required for 4-level protocols. RFi-148 has an extra, general purpose input “Aux Input 1,” for a combined total of 10. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual...

  • Page 22: Operation

    Serial Ports -> [Rear|Front] Settings 4.1 Serial Port Operation 4.1.1 Overview The RFI-148/900250 has two RS-232 serial ports, providing support as shown in Table 1. The serial port pin-outs can be found in Appendix A.3 on page 45. Serial Ports...

  • Page 23: Ethernet Operation

    4.3 Transmitter Operation Radio -> Power 4.3.1 Transmit Power The RFI-148/900250 supports transmit power from 20 to 250 Watts in 1 Watt increments. POWER FOLDBACK The power foldback is a configurable percentage which calculates the power to foldback to when the scale transmit power fault action is latched.

  • Page 24: Push-To-Talk (Ptt)

    Software PTT is available using Hayes AT commands, through the Cruise Control GUI, or through the terminal menu interface. It is also selected implicitly when enabling TNPP or PET/TAP on either a serial or Ethernet stream. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 23 of 99...
  • Page 25 The unit is in Standby due to the Hot Standby operation (see section 7 Hot Standby Operation). PTT is enabled once the source of the override is addressed. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 24 of 99...

  • Page 26: External Reference

     3 µs. Absolute delay adjustment can be used for matching delay in:  Simulcast networks where transmitters from different manufacturers are used. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 25 of 99...

  • Page 27: Rf Diagnostics

    When using 4-level FSK the deviation with respect to the H and L bits is outlined in Table 6 below. Note that two interpretations of the H-bit/L-bit are available, denoted as “Legacy” and “Normal” and configurable RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 26 of 99...

  • Page 28: Carrier Offset

    There is a fan override feature available to force the fans to turn on at full speed. When fan override is set to always on the fans will turn on and ignore the reference temperature. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 27 of 99...

  • Page 29: Self-Test

    The fan controller has a self-test feature which causes the fans to run at full speed for a minute so fan operation can be verified. The self-test feature runs once every 24 hours by default. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 28 of 99...

  • Page 30: Diagnostics

    A non-latching fault will only be cleared once it has returned to within its cut-offs while its checking condition is met. A latching fault must be cleared in software. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 29 of 99...

  • Page 31: Minimum And Maximum Sensor History

    Transmit power is reduced to a configured percentage. See section 0.  Enable PA current fold-back: The PA current fold-back is engaged.  Enable reverse power fold-back: The reverse power fold-back is engaged. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 30 of 99...

  • Page 32: Fleeting Faults

    Once the upload is finished, the status will display “Monitoring”. Note that at this point the firmware image has not been applied. The firmware image is kept in non-volatile storage until it is required. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 31 of 99...

  • Page 33: Snapshot

    The paging transmitter has a firmware “Snapshot” used for recovering the paging transmitter to a previous state. The snapshot contains a backup of the current firmware and configuration. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 32 of 99...

  • Page 34: Time

    The SNTP client can be disabled or set to unicast mode. In unicast mode, the paging transmitter will query the configured time server for time updates at a configurable interval. By default the SNTP client is disabled. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 33 of 99...

  • Page 35: Internal Encoding

    The RFI PTX supports a set of rules that trigger the repetition of a submitted page messages. When a rule is enabled any messages which match the cap code will be repeated Count number of times every Delay seconds. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 34 of 99...

  • Page 36: Protocols Supported

    '3', '4', '5', '6', '7', '8', '9', '!', 'U', ' ', '-', ']', '['). Paging Protocols -> TAP/PET 6.3.3 TAP The TAP protocol is treated the same as PET, however with some extensions: RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 35 of 99...

  • Page 37: Page Datagram

     <header>: The generic header shown in Figure 14 with the type field set to 0  Message length (2): The length of the “Message (x)” field (the only variable length portion of this packet) RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 36 of 99...
  • Page 38 0x4: Page submission failed: general error o 0x10: Nothing was performed – this is a link test reply  <footer>: The generic footer shown in Figure 14. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 37 of 99...

  • Page 39: Test Functions

    6.4 Test Functions When internal encoding is enabled the RFI PTX can generate test messages as a simple means to confirm site operation or perform extended site surveys. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 38 of 99...

  • Page 40: Hot Standby Operation

    (Secondary) Figure 18: Hot standby system The RFI-PHSB contains a high power RF switch to ensure minimal signal loss from the active RFI-148 250 to the antenna. The pair of RFI-148 250 transmitters assume either a Primary or Secondary role. The role of the transmitter is determined by which port it is connected to the RFI-PHSB, there are two ports “Primary”...

  • Page 41: Operation

    7.3 Operation The Primary RFI-148 250 has control of the RF switch position. The default switch position, when no Primary unit exists or the RFI-PHSB is unpowered, is for the Secondary unit. Upon power up the Primary unit will always favour itself for the RF switch position, but the power up default is to leave the switch in the Secondary unit position.
  • Page 42 Appendix A Technical Specifications  IS PRIMARY (LIU pin 24): Active if the unit is the Primary unit RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 41 of 99...

  • Page 43: Appendix A Technical Specifications

    Internal Reference Frequency: 10 MHz Stability: +/- 1 ppm (-30 to +75 degrees C) External Reference Frequency: 5 or 10 MHz Amplitude: -20 to 15 dBm RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 42 of 99...
  • Page 44 DC Power: Terminal block Phoenix Contact 1703454 and cable mount plug Phoenix Contact 1967456. Front Serial Port: DE-9 RS-232 Female (DCE) LIU Interface: DC-37 Female Ethernet: RJ45 socket RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 43 of 99...
  • Page 45 20 W: 2.01 A  50 W: 2.84 A  100 W: 3.93 A  200 W: 5.56 A  250 W: 6.22 A Table 11: RFI-900 current draw RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 44 of 99...

  • Page 46: Serial Connectors

    Table 13: Front Connector Pin Out A.4 LIU Interface Function Label Direction Protocol Select Input Alarm 3 ALM3 Output Alarm 10 ALM10 Output Alarm 11 ALM11 Output RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 45 of 99...
  • Page 47 +24V RFI-900 +24 V nominal (Note: identical to DC RFI-148 Output input voltage for 24 VDC model) A general purpose input available on the RFI-148 only. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 46 of 99...
  • Page 48 Open collector MOSFET Open collector Darlington Maximum sink current 500 mA 50 mA Maximum output voltage 50 V 12 V Table 16: LIU Alarm Output Specifications RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 47 of 99...

  • Page 49: Appendix B Controller Configurations

    B.3 Glenayre C2000 Controller / POCSAG Mode Encoder Transmitter (LIU, DC37) Tx Data DC37-15: LB DC37-11: PTT DC37-19: GND Table 19: Glenayre C2000 Controller / POCSAG Mode Connection RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 48 of 99...

  • Page 50: Zetron Model 66 Transmitter Controller / Pocsag Mode

    DIG DATA (pin 10) DC37-15: LB DIG PTT (pin 7) DC37-11: PTT GND (pin 3) DC37-19: GND Table 20: Zetron Model 66 Controller / POCSAG Mode Connection RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 49 of 99...

  • Page 51: Appendix C Management Reference

    The number of transmit overflow errors that have occurred. This occurs when there is data to transmit, but the buffer is full. Table 21: Serial Port Statistics RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 50 of 99...

  • Page 52: Snmp Diagnostic Parameters

    An approximation of the total number of hours that this device has been powered up. rfiIdProdstr The model name for this device. rfiIdSerialno Factory assigned serial number for this device. Paging Protocols RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 51 of 99...
  • Page 53 Transmit Timeout fault to occur. By default this will disable further transmission until the fault is cleared. rfiRadioTxTimeouten Enable or disable the transmit timeout feature. Sensors RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 52 of 99...
  • Page 54 Minimum recorded sensor value since the statistics were reset. rfiSensTblName Name of the fault in this row of the table. rfiSensTblVal Current measured sensor value. Table 22: SNMP Diagnostic Parameters RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 53 of 99...

  • Page 55: Appendix D Hayes At Reference

    Initialise the length for a .ruf file transfer ATU1=n: Runs the RUF Init routine where n is the length of the .ruf file in bytes. RUF Block RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 54 of 99...
  • Page 56 ATP119: Returns the current value of Current Transmit Time. Transmitter Idle Time Time since last transmission ended (if not transmitting), or zero if currently transmitting. ATP116: Returns the current value of Transmitter Idle Time. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 55 of 99...
  • Page 57 ATS209: Returns the current value of Max Tx Power. ATS209=n: Sets the value of Max Tx Power to n W, given that 20 <= n <= 250. Tx Power RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 56 of 99...
  • Page 58 ATS211: Returns the current value of Tx Base Freq. ATS211=n[.m]: Sets the value of Tx Base Freq to n MHz, given that 130.000000 <= n <= 1050.000000. (Distributer) Bandwidth RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 57 of 99...
  • Page 59 ATI123: Returns the current value of External Reference. Reference Mode The reference selection method. ATI120: Returns the current value of Reference Mode. ATI120=n sets Reference Mode to n Values accepted: RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 58 of 99...
  • Page 60 Encoding Mode Configure the encoding source for paging transmitter data. ATN10: Returns the current value of Encoding Mode. ATN10=n sets Encoding Mode to n Values accepted: RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 59 of 99...
  • Page 61 Option to skip login sequence if a <STX> is read while waiting for wake up sequence. ATN42: Returns the current value of Implied Login. ATN42=n sets Implied Login to n Values accepted: 0 = Disabled 1 = PG1 2 = PG3 RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 60 of 99...
  • Page 62 Transparent CRC support ATN25: Returns the current value of Transparent CRC support. ATN25=n sets Transparent CRC support to n Values accepted: 0 = False 1 = True RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 61 of 99...
  • Page 63 ATN11=n sets Function Override to n Values accepted: 0 = Message Encoding 1 = Always 00 2 = Always 01 3 = Always 10 4 = Always 11 RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 62 of 99...
  • Page 64 ATN35[a]: Returns the current value of Count. Where: a = POCSAG MAC Statistics table index (starting from 0) Test Menu Status ATG171: Returns the current value of Status. Message RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 63 of 99...
  • Page 65 ATG180: Runs the Begin Survey routine. Stop Survey ATG181: Runs the Stop Survey routine. Send One Message ATG182: Runs the Send One Message routine. Advanced Menu Custom Deviation RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 64 of 99...
  • Page 66 ATP111: Returns the current value of Time Until Fan Test. Fan Override Manual fan override (allows fans to be forced on). ATP22: Returns the current value of Fan Override. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 65 of 99...
  • Page 67 1 = Enabled (Distributer) Fail-safes ATI204: Returns the current value of Fail-safes. ATI204=n sets Fail-safes to n Values accepted: 0 = Disabled 1 = Enabled Sensor Configuration Menu RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 66 of 99...
  • Page 68 ATI97[a]=n: Sets the value of Hysteresis to n , given that 0 <= n <= 65535. Where: a = Status Parameters table index (starting from 0) Lower Cutoff RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 67 of 99...
  • Page 69 ATG163[a]=[+/-]n: Sets the value of 200W Lower Cutoff to n , given that -2147483648 <= n <= 2147483647. Where: a = Transmit Power Variation table index (starting from 0) RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 68 of 99...
  • Page 70 ATI157: Returns the current value of Active Faults. Combined Fault Status The status of the combined alarm. ATI158: Returns the current value of Combined Fault Status. Overview Filter RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 69 of 99...
  • Page 71 ATI174=n sets Fault Beeper to n Values accepted: 0 = Never 1 = Activity 2 = Heartbeat Reset Counters ATI163: Runs the Reset Counters routine. Faults Table Fault Name RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 70 of 99...
  • Page 72 4 = Enable PA0 Current Foldback 5 = Enable PA90 Current Foldback 6 = Enable Reverse Power Foldback Where: a = Faults table index (starting from 0) Latching Mechanism RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 71 of 99...
  • Page 73 Where: a = Faults Overview table index (starting from 0) Counter ATI162[a]: Returns the current value of Counter. Where: a = Faults Overview table index (starting from 0) Encoder Interface Menu RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 72 of 99...
  • Page 74 0 = Disabled 1 = Enabled Encoder Hardware PTT Allows transmitter PTT to be controlled by hardware input. ATP97: Returns the current value of Encoder Hardware PTT. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 73 of 99...
  • Page 75 Configures the clock edge to use when using an external data clock. ATI152: Returns the current value of Clock Edge. ATI152=n sets Clock Edge to n Values accepted: RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 74 of 99...
  • Page 76 Can Go Active (HW) ATM11: Returns the current value of Can Go Active (HW). TX Fault ATM16: Returns the current value of TX Fault. Standby Mode RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 75 of 99...
  • Page 77 ATS91: Returns the current value of Main CTS Mode. ATS91=n sets Main CTS Mode to n Values accepted: 0 = Always High 1 = Always Low 2 = Mirrors DCD RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 76 of 99...
  • Page 78 ATS103[a]: Returns the current value of Stop Bits. ATS103[a]=n sets Stop Bits to n Values accepted: 0 = 1 1 = 2 Where: a = Settings table index (starting from 0) Reset Statistics RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 77 of 99...
  • Page 79 0 = 10 Mbps 1 = 100 Mbps Forced Link Duplex Configures duplex when the link parameters are forced. ATR261: Returns the current value of Forced Link Duplex. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 78 of 99...
  • Page 80 ATI80[a]=n: Sets the value of 1st Octet to n , given that 0 <= n <= 255. Where: a = Static IP Configuration table index (starting from 0) RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 79 of 99...
  • Page 81 ATG6=n[.m]: Sets the value of Request Timeout to n s, given that 0.000 <= n <= 65.535. Send Request ATG7: Runs the Send Request routine. UDP Connections Table RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 80 of 99...
  • Page 82 Version information for the FPGA image loaded into this device. ATI18: Returns the current value of FPGA Version. Bootloader Version ATI130: Returns the current value of Bootloader Version. (Distributer) Assertion Messages RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 81 of 99...
  • Page 83 1 = ''DD/MM/YYYY'' 2 = DD/MM/YYYY 3 = ''DD/MM/YYYY HH:MM:SS'' 4 = DD/MM/YYYY HH:MM:SS 5 = ''YYYY/MM/DD HH:MM:SS'' 6 = YYYY/MM/DD HH:MM:SS Time Zone (UTC +/-) Table Hours RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 82 of 99...
  • Page 84 ATU15: Runs the Roll Back to Snapshot routine. Firmware Update Table ATU48[a]: Returns the current value of . Where: a = table index (starting from 0) Available RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 83 of 99...
  • Page 85 Ethernet Data Statistics Table Name Value ATR303[a]: Returns the current value of Value. Where: a = Ethernet Data Statistics table index (starting from 0) IP Statistics Menu RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 84 of 99...
  • Page 86 Where: a = Protocol Statistics table index (starting from 0) Routing Error ATG45[a]: Returns the current value of Routing Error. Where: a = Protocol Statistics table index (starting from 0) Protocol Error RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 85 of 99...
  • Page 87 ATS182[a]: Returns the current value of Status. ATS182[a]=n sets Status to n Values accepted: 0 = Disabled 1 = Enabled Where: a = Filters table index (starting from 0) RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 86 of 99...
  • Page 88 Where: a = Transmission Log table index (starting from 0) Event ATP114[a]: Returns the current value of Event. Where: a = Transmission Log table index (starting from 0) RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 87 of 99...

  • Page 89: Appendix E Sensor And Fault List Reference

    0 to 21977 Isolator VSWR 0 to 9000 2500 Table 23: Sensor Reference Measurement varies according to Tx Power – these values apply to Tx Power = 250W. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 88 of 99...
  • Page 90 Low Driver Temperature Configurable None None Low PA Ambient Temperature Configurable None None Low Isolator Temperature Configurable None None Low Baseband 1 Temperature Configurable None None RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 89 of 99...
  • Page 91 Disable Transmit None Invalid Calibration Latch-only Disable Transmit None Watch Dog Reset Latch-only None None Assertion Reset Latch-only None None Firmware Update Exception Latch-only None None RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 90 of 99...
  • Page 92 None Enable PA0 Current Foldback Latch-only None None Enable PA90 Current Latch-only None None Foldback Enable Reverse Power Latch-only None None Foldback Table 24: Fault Reference RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 91 of 99...

  • Page 93: Appendix F Product Identification Table

    For example, the product code for a 250 W Paging Transmitter supplied from -48 VDC, with an integrated isolator and released for Europe is RFI-148 250TCDE. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 92 of 99...

  • Page 94: Appendix G Troubleshooting

    20 W transmit power, including reasonable sensor cutoffs for this transmit power. If the transmit power is increased, then the sensor cutoffs also need to be similarly increased. Please contact STI Engineering for accessing Cruise Control configuration files with recommended sensor cutoffs for common transmit power settings.

  • Page 95: External Reference Fail

     Ensure the external reference is plugged in.  Ensure the external reference is within specification (see Table 9).  Ensure the external reference frequency is configured correctly. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 94 of 99...

  • Page 96: High Transmit Power

    250 W with an ambient temperature of 60 °C, the paging transmitter is expected to reach 80 °C. Ensure proper air circulation and/or air conditioning in the area the paging transmitter is installed. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 95 of 99...

  • Page 97: Unit Won't Transmit

    G.2.4.2 High Reverse Power or Reverse Power Foldback A high reverse power fault indicates a hardware failure of the circulator inside the paging transmitter. Failure of the circulator can cause RF spectrum splatter, so transmit is disabled. Return the unit to STI Engineering for repair.

  • Page 98: Hardware Or Auto Ptt

    There are no faults active. A unit configured to transmit at a high power level needs similarly higher sensor cutoffs, see appendix G.1. Otherwise, low transmit power could indicate a hardware failure. If troubleshooting fails, return the unit to STI Engineering for repair. RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 97 of 99...

  • Page 99: Appendix H Glossary

    Telelocator Alphanumeric Protocol (formerly PET) Threaded Neill-Concelman (Connector) TNPP Telelocator Network Paging Protocol Transmitted Coordinated Universal Time Very High Frequency VSWR Voltage Standing Wave Ratio Table 26: Glossary RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 98 of 99...
  • Page 100 PTT System Override ............ 24 Paging Transmitter ............42 PTT Turn Off Delay ............24 Serial Ports ..............45 Sensor Cut-off ............... 29 Serial Ports ..............21 RFI-148 & RFI-900 High Output Power Paging Transmitters User Manual Page 99 of 99...
