Scandvik Hot Waves 80001 User Manual

Marine Water Heater User Guide
#80000 W/O Heat Exchanger, 110V
#80001 With Heat Exchanger, 110V
Application
Capacity
Internal tank material carbon steel hot roll ASTM-A36
Internally Coated
External cover fiberglass / gelcoat color white
Polyurethane foam insulation
Inner surface preparation Sand-blasting with metal
Particles Type SSPC-10
Sacrificial magnesium anode
Inlet / outlet water connections
Pressure / temperature safety valve coupling
Pressure / temperature safety valve
Maximum Operating Pressure
Recovery time (ΔT: 45°F)
Threaded heating element
Ignition protected fixed limit thermostat
Standard engine heat exchanger formed stainless steel
UL & CSA Approvals
Warranty
Marine
6 gallons
Caps and cylinder thickness 2.4mm
This protection provides a bond with the metal substrates
and excellent corrosion protection. Powder coating Dupont,
Alesta ELW505S9, in accordance with FDA standards
Resistant to corrosion and marine environment / can be
used as step
To reduce heat loss
Clean the inner surface of carbon, oil and corrosion and
prepares for implementation of epoxy
Provides corrosion protection that extends the life of the
tank
1/2" NPT-male
1/2" NPT-female
210º F and/or 150 psi. Located on the front of the tank the
T&P valve is included
125 psi
25 minutes to raise water temperature 45° F
110 VAC, 1500 W (available in various wattages and volt-
ages)
Temperature adjustment (Low, Medium, High)
Continuous 316 SS tubing, no internal joints
T&P Valve, Thermostat and Heating Element
2-year full warranty, 5-year warranty on tank
www.scandvik.com
(800) 535-6009
Can be used as a step
