Abax ACU-100 User Manual

Wireless system controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
abax
two-way
wireless
system
WIRELESS SYSTEM CONTROLLER
ACU-100
Program version 3.00
User Manual
1471
acu100_en 05/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACU-100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Abax ACU-100

  • Page 1 WIRELESS SYSTEM CONTROLLER ACU-100 Program version 3.00 User Manual 1471 acu100_en 05/11...
  • Page 2 Product description: The ACU-100 wireless system controller designed for interaction with other elements of the ABAX wireless system. The device operates in the 868.0 MHz – 868.6 MHz frequency band, and is supplied from a 12 V DC source. The controller is intended to be used in burglary and panic alarm systems and can be connected to any type of the alarm control panel.
  • Page 3 ACU-100 SATEL New features of the ACU-100 controller with firmware version 3.00 • Support for a new wireless device by the controller interacting with the INTEGRA control panel with firmware version 1.09 or later: – ATD-100 – wireless temperature detector.

  • Page 4: Table Of Contents

    LCD keypad ..........................18 5. Hardwired zone/output expanders in ABAX system ............18 5.1.1 Configuration of ACX-200 or ACX-201 expander zones/outputs for ACU-100 controller operation with INTEGRA or VERSA control panel ..............19 5.1.2 Configuration of ACX-200 expander zones/outputs for ACU-100 or ACX-201 controller operation with CA-64 control panel.....................
  • Page 5 7.2 Description of ASP-205 siren functioning................. 23 7.3 Additional siren parameters to be configured................24 8. ASW-100 230V AC wireless controllers in ABAX system..........24 9. Radio signal level tester in ABAX system................ 25 10. Interaction with alarm control panels ................26 10.1 Expander of wireless devices for INTEGRA series control panels...........

  • Page 6: General

    ESCRIPTION OF WIRELESS SYSTEM CONTROLLER The ACU-100 controller supervises and coordinates operation of up to 48 wireless devices. The status of devices is signaled on the OC type outputs. It can also be transmitted to the control panel through the communication bus.
  • Page 7 ACU-100 SATEL - information output – no radio communication with wireless devices - information output – radio jamming - information output – problems with wireless devices power supply or with supply output overload in the ACX-201 expander. OUT1…OUT8 - information output – wireless equipment status - control inputs AR1…AR4...

  • Page 8: Functions Of Dip-Switches

    Two-way wireless system ABAX ACU-100 DIP- UNCTIONS OF SWITCHES DIP-switch number Controller function Wireless device module for all control panels Expander for CA-10 with 1 keypad (6 zones) Expander for CA-10 with 2 keypads (4 zones) Expander for CA-10 with 3 keypads (2 zones)
  • Page 9 The number of inputs can be increased by connecting the ACX-100 expansion modules to the controller. The number of control inputs in the ABAX system can be up to 24 (controller + 5 ACX-100 modules). In order to control the ACU-100 controller inputs you can use any alarm control panel outputs (OC, high-current, low-current, relay type).

  • Page 10: Outputs

    The PCB of the ACU-100 controller incorporates eight OC type outputs, to which wireless devices are assigned. Any number of wireless devices can be assigned to one output. The number of outputs can be increased by connecting the ACX-100 expansion modules to the controller.

  • Page 11: Wireless Devices Interfacing With The Controller

    After connecting the functional outputs to properly programmed zones of the control panel (zone type, function, etc.), the control panel may signal occurrence of some problems in the ABAX system. The problems can be diagnosed by means of LCD keypad or computer connected to the controller.

  • Page 12: Apmd-150 Wireless Dual Motion Detector

    Two-way wireless system ABAX ACU-100 • power supply: lithium battery, CR123A 3V APMD-150 W IRELESS DUAL MOTION DETECTOR • microwave (MW) sensor and double pyroelectric (PIR) element • advanced power management • high immunity to interference and false alarms • independent sensitivity adjustment for PIR and MW •...

  • Page 13: Avd-100 Wireless Vibration Detector And Magnetic Contact

    ACU-100 SATEL 3.11 AVD-100 W IRELESS VIBRATION DETECTOR AND MAGNETIC CONTACT • advanced processing of piezoelectric sensor signal • vibration detection sensitivity adjustment • remote configuration • tamper contact • power supply: lithium battery, CR123A 3V 3.12 ASD-100 W IRELESS SMOKE AND HEAT DETECTOR •...

  • Page 14: Apt-100 Bidirectional Keyfob

    • power supply: alkaline battery 9 V 6LR61 4. I NSTALLATION The ABAX two-way wireless system should be installed so as to ensure a suitable level of radio signal from devices working together with the controller. This will allow the communication problems to be avoided.

  • Page 15: Installation Of Acu-100 Wireless System Controller

    RJ socket is shown in Fig. 3. Address of the keypad to be connected to the ACU-100 controller must be set as 0. If properly connected, the keypad will display a message, the upper line of which will include the device name and program version info.

  • Page 16: Connecting Computer To The Controller

    6. Connect the keypad to the ACU-100 controller as required (CKM, DTM). ONNECTING COMPUTER TO THE CONTROLLER If the ACU-100 controller is to be programmed by means of a computer, the computer must be connected to the RS-232 port. Connection between the controller RS-232 port and the computer port should be made as shown in the picture below (you can buy a ready-made cable manufactured by SATEL).

  • Page 17: Connecting The Acx-100 Input & Output Expansion Modules

    INPUT OUTPUT EXPANSION MODULES The ACU-100 controller communication bus can accept up to five ACX-100 input & output expansion modules. The modules can only be connected when the controller is configured as a wireless device module interfacing with any alarm control panel.

  • Page 18: Adding New Wireless Devices

    „Abort” button. You can also add a next wireless device by pressing the „Next” button. Note: If the ACU-100 controller is configured for operation as the expander with the CA-64 or INTEGRA control panels, the procedure of adding new wireless devices to the system...

  • Page 19: Lcd Keypad Connected To The Controller

    ACU-100 SATEL 4.5.2 LCD keypad connected to the controller In order to add a new wireless device to the system, do the following: 1. Start the N function. EW DEVICE 2. Enter the 7-digit serial number of the device to be added and press the [#] key. The serial number can be found on the electronics board or on the housing.

  • Page 20: Removal Of Wireless Devices

    3. Following the displayed instruction, press the "Yes" button to confirm your intention to remove the device. The device will be removed. Note: If the ACU-100 controller is configured for operation of the expander with CA-64 or INTEGRA control panels, a new identification of expanders must be carried out after completion of the procedure of removal of a new wireless device from the system.

  • Page 21: Configuration Of Acx-200 Or Acx-201 Expander Zones/Outputs For Acu-100 Controller Operation With Integra Or Versa Control Panel

    ACU-100 SATEL Note: If the communication with the ACU-100 controller is lost, all of the previously activated outputs will enter the inactive state after 20 response periods. Additionally, the ACX-201 expander will transmit information on: – status of AUX1, AUX2 supply outputs – overload information is sent when the AUX1 or AUX2 output load exceeds 0.5 A.

  • Page 22: Configuration Of Acx-200 Or Acx-201 Expander Zones/Outputs For Acu-100 Controller Operation With Other Control Panels

    Irrespective of how the expander zones will be programmed, the control panel zones to which the ACU-100 controller outputs will be connected, are to be configured as NO or NC type (see also section I...

  • Page 23: Additional Detector Parameters To Be Configured

    VERSA series control panels, select the corresponding option for wireless detector. Otherwise, the controller input for detector control should be programmed as always active. According to the EN50131-3 standard all Hold-Up devices used with ACU-100 controller must be always in active mode.

  • Page 24: Sirens In Abax System

    IRENS IN SYSTEM The sirens sent information on tampers and (storage) battery/power supply status to the ACU-100 controller. The information on tampers is sent immediately, while all the other information - at the response time (see: R ESPONSE PERIOD Note: Signaling of the tamper alarm is blocked: –...

  • Page 25: Description Of Asp-105 Siren Functioning

    ACU-100 SATEL Depending on the controller operating configuration, the signaling is triggered: – on activating the output of INTEGRA or VERSA system to which the wireless siren is assigned. The output is to be suitably programmed. – on activating the controller input which has been selected as the control one.

  • Page 26: Additional Siren Parameters To Be Configured

    SYSTEM The 230 V AC wireless controller: – takes up 1 position on the list of wireless devices supported by the ACU-100 controller; – occupies 1 output and 1 zone in the INTEGRA or VERSA alarm system; – takes up 1 zone and additionally requires 1 ACU-100 controller input to control operation in the CA-64 or CA-10 alarm system;...

  • Page 27: Radio Signal Level Tester In Abax System

    ADIO SIGNAL LEVEL TESTER IN SYSTEM The ARF-100 tester takes up one position on the list of devices supported by the ACU-100 controller. The tester enables checking the level of radio signal received either by the controller from the tester, or by the tester from the controller. The signal level is displayed on the tester LEDs, when the ACU-100 controller is running in the test mode.

  • Page 28: Interaction With Alarm Control Panels

    +EX2 Table 6. Having connected the ACU-100 controller to the control panel, start the expander identification function in the panel. In the process of addition or removal of the wireless devices, it must be borne in mind that during controller identification the INTEGRA series control panels register the zones and outputs by groups of 8.
  • Page 29 INTEGRA 64 / INTEGRA 128 +12V ACU-100 TPR CON JAM LBA OUT1 OUT2 OUT3 OUT4 OUT5 OUT6 OUT7 OUT8 COM AR1 AR2 AR3 AR4 Fig. 8. Example of connecting the ACU-100 controller to the INTEGRA control panel. INTEGRA 64/128 ACU-100 zones...

  • Page 30: Addressable Zone Expander For Ca-64 Control Panel

    Control of the detectors (changeover to active/passive state), sirens (triggering alarm signal), 230 V AC controller (closing/opening the electric circuit) etc. is performed through the control inputs of the ACU-100 controller. Suitably programmed outputs of the alarm control panel should be connected to the control inputs.
  • Page 31 LOAD Fig. 9. Example of setting the DIP-switches. Fig. 10 shows a configuration example of the ACU-100 controller working together with the CA-64 control panel. The controller communication bus is connected to the second expander bus of the control panel. The OUT9 panel low-current output has been programmed as type 42: P and connected to the AR1 controller control input.

  • Page 32: Zone Expander For Ca-10 Control Panel

    Using the DIP-switches, set the suitable operating mode, address and programming mode of the ACU-100 controller. To determine the operating mode you should take into account the number of keypads installed in the system. Depending on the number of keypads, the...
  • Page 33 CLK2 panel terminal. The zones made available by the ACU-100 controller to the control panel by means of the communication bus have in the security system numbers from 11 to 16 (controller outputs from 11 to 16). These zones should be programmed in the control panel as 2EOL/NO type.

  • Page 34: Wireless Device Module Interfacing With Any Alarm Control Panel

    10.4 W IRELESS DEVICE MODULE INTERFACING WITH ANY ALARM CONTROL PANEL Using the DIP-switches, set the suitable operating mode of the ACU-100 controller, number of ACX-100 modules which are connected to it, as well as the programming mode. number of ACX-100 modules:...

  • Page 35: Programming And Diagnostics

    Control of the detectors (changeover to active/passive state), sirens (triggering alarm signal), 230 V AC controller (closing/opening the electric circuit) etc. is performed through the control inputs of the ACU-100 controller. Suitably programmed outputs of the alarm control panel should be connected to the control inputs.

  • Page 36: Lcd Keypad Of Versa Alarm System

    ). After selecting the controller from the list to be displayed, the programming ETTINGS should be conducted according to the "step by step" method. The other programming related functions of the ABAX system are available in the ACU-100 submenu (S 2. H 1.
  • Page 37 ACU-100 SATEL Fig. 15. Configuration of the ACU-100 controller working together with the INTEGRA control panel in D X program. Given under information on the module type and address is the LOAD version of its firmware. The wireless devices have been registered in the controller as recommended earlier in this manual: the devices which occupy both zones and outputs in the system were added first, while the devices taking up zones only were added after them.

  • Page 38: Lcd Keypad Connected To Controller

    Fig. 16. D X program window showing signal level and quality of controller LOAD communication with wireless devices (ACU-100 controller working together with the INTEGRA control panel). Troubles of wireless devices (no communication, low battery level, jamming) can be read out...

  • Page 39: Dload10 Program

    1234 by default and can be changed to any sequence of 16 characters). 4. Open the "Communication" menu, select the "Configuration" item and indicate the computer port to which the controller is connected. 5. Open the "File" menu, select "New device", and then "ACU-100".
  • Page 40 Also the level of radio signal received by the controller from individual devices can be represented in a diagrammatic form. Note: When the ACU-100 controller operates in configuration of expander of wireless devices for the INTEGRA series control panels, the options regarding configuration of wireless devices are not available in the D 10 program.
  • Page 41 ACU-100 SATEL...

  • Page 42: Description Of Functions, Options And Commands

    Two-way wireless system ABAX ACU-100 Fig. 19. D 10 program window with a diagram of the level of radio signal received by the LOAD controller. 11.6 D ESCRIPTION OF FUNCTIONS OPTIONS AND COMMANDS Identifier – the identifier in the D...
  • Page 43 ACU-100 SATEL Notes: • When a new wireless device is added to the system, the input 1 is indicated by default as the control input. • When the entered input number is higher than 24, the input to control the device will be always active.
  • Page 44 Two-way wireless system ABAX ACU-100 given in the user menu, T submenu, and in the D X program, in the ROUBLES LOAD "Troubles" window. Tamper state – this function, available in the LCD keypad connected to the controller, allows you to check which of the wireless devices are or were tampered with. In the D...

  • Page 45: Configuration Of Additional Parameters And Options In Wireless Devices

    The test is carried out in the on-line mode, and its results are visualized as the Communication quality in percentage form. Synchronization – the ACU-100 controller checks whether other wireless systems are operating within its range, and if so, it adjusts the response time accordingly.

  • Page 46: 12.1.3 Amd-100 And Amd-101 Detectors

    Two-way wireless system ABAX ACU-100 digit – sensitivity of microwave path: from 1 to 8 (1 – minimum; 8 – maximum), digit – type of operation in the test mode: 0 (signaling violation after motion is sensed by both detectors), 1 (signaling violation after motion is sensed by infrared detector) or 2 (signaling violation after motion is sensed by microwave detector).

  • Page 47: Ard-100 Detector

    ACU-100 SATEL For example, entering the 0-2-4 means that the heat detector has been disabled, acoustic signaling type 2 has been selected, and the signaling by means of buzzer/LEDs will last 9 minutes. 12.1.8 ARD-100 detector Enter a digit from the 1 to 16 range, corresponding to the selected sensitivity (1 – minimum;...

  • Page 48: Lcd Keypad

    Two-way wireless system ABAX ACU-100 12.2 LCD KEYPAD In the LCD keypad of INTEGRA system, additional parameters and options of the wireless devices are to be programmed by means of the C function (S ONFIGURATION ERVICE MODE TRUCTURE ARDWARE XPANDERS...

  • Page 49: Avd-100 Detector

    ACU-100 SATEL 12.2.6 AVD-100 detector After selecting the first position / the first zone occupied by the AVD-100, the keys allow you to indicate the active reed switch of the magnetic contact. After selecting the second position / the second zone occupied by the AVD-100 detector, the parameters of the vibration detector can be configured.

  • Page 50: 12.2.12 Asw-100 E And Asw-100 F Controllers

    Two-way wireless system ABAX ACU-100 12.2.12 ASW-100 E and ASW-100 F controllers Use the keys to select the operating mode of the ASW-100 controller. 13. R ESTORING CONTROLLER DEFAULT SETTINGS The following parameters are preprogrammed by default: • service code: 12345;...

  • Page 51: History Of The Manual Updates

    ACU-100 SATEL 15. H ISTORY OF THE MANUAL UPDATES Described in the table below are changes as compared with the manual for the ACU-100 controller with firmware in version v1.03. IRMWARE NTRODUCED CHANGES VERSION • Added information on the options of programming the outputs of the controller and 2005-09 1.04...
  • Page 52 • Added information about the method of configuration of CA-64 system zones to which wireless devices are assigned (p. 30). • Added subsection about programming ABAX wireless system by means of VERSA alarm system keypad (p. 34). • Added subsection about configuration of additional parameters and options of wireless devices (p.
