SecurityMan CARCAMGPS User Manual

Full hd car camera with gps log
Hide thumbs
Table of Contents

Advertisement

Quick Links

User's Guide
FULL HD CAR CAMERA WITH
GPS LOG
Model: CARCAMGPS ™

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CARCAMGPS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SecurityMan CARCAMGPS

  • Page 1 User’s Guide FULL HD CAR CAMERA WITH GPS LOG Model: CARCAMGPS ™...
  • Page 2 Limitation of Liability The liability of SecurityMan Inc, arising from this warranty and sale shall be limited to a refund of the purchase price. In no event shall SecurityMan be liable for costs of procurement of substitute products or services, or for any lost profits, or for any consequential, incidental, direct or indirect damages, however caused and on any theory of liability, arising from this warranty and sale.

  • Page 3: Table Of Contents

    Syncing gesture and impact events Formatting your memory card Playing back events From the App gallery From the memory card Transferring events from the memory card gallery to the App gallery CARCAMGPS App App section Camera Tab First time user’s tutorial Connect Travel Tab...
  • Page 4 Connection Verification Video With Snapshot Audio Recording Gesture Snapshots Video Resolution G-Sensor Sensitivity Synchronize Time & Date Volume Storage Management Version Disconnect Form Camera Live View Icons Live View Playback App Download iPhone Android Specifications...

  • Page 5: Introduction

    Introduction The SecurityMan CARCAMGPS lets you capture crystal clear HD footage with time, speed & location data so you can easily keep track of scenic travel, traffic accidents and any unexpected moments as they occur. Both video and audio are automatically recorded in an endless loop...
  • Page 6 In order for the camera to lock the file being recorded. • Please use the camera as a tool while driving and use driver’s safety while driving. • SecurityMan Inc shall not be held responsible for any traffic violations related to the position- ing or improper use of our product.
  • Page 7 • GPS connection time will vary depending on the signal strength and dongle positioning. Please wait for the GPS connected voice prompt before moving the vehicle. Package Contents CARCAMGPS Mounting Bracket GPS Power Cable 2 Port USB Adapter 2.4A for CARCAMGPS Warning Stickers User’s Manual Quick Start Guide...

  • Page 8: Product Basics

    Product Basics Phone connected LED (Green) • Solid: Connected to a mobile device (Smartphone, Tablet, etc) via the SM CARCAMGPS app. Recording LED (Red) • Flashing steadily: Recording. • Solid: No memory card present. Reset • Press and hold: Resets the camera to its factory default settings.

  • Page 9: Quick Start Guide

    Quick Start Guide The following will guide you through a quick setup process and a couple setting changes that will need to be configured before using your camera. IMPORTANT • Always keep your eyes on the road and never take both hands off the steering wheel when using the hand-gesture feature.
  • Page 10 ATTACHING THE BRACKET To attach the suction cup mounting bracket, slide the small square shaped tip of the bracket into the small opening located at the top of the camera. You can easily detach the camera when needed by reversing the step. MOUNTING THE CAMERA IMPORTANT •...
  • Page 11 Remove the suction cup protected over lay. With the suction cup in the “unlocked” position, place it on your windshield and lock it into place by moving the Suction Lever upwards towards the windshield. Once the suction cup is securely mounted t o your windshield you can move the camera up, down, left and right to adjust its view as needed.

  • Page 12: App Download

    Please wait for the GPS connected voice prompt before moving the vehicle. APP DOWNLOAD The SecurityMan SM CARCAMGPS app can be found on both IOS and Android platforms by simply scanning the corresponding QR code below or searching for it in the Apple App-Store or Google Play- Store.
  • Page 13 Launch the SM CARCAMGPS on your cell phone and tap on “Connect”. Read the “No Cam- era Connected” prompt and tap on “Ok” to open your phones Wi-Fi settings. On the Wi-Fi settings screen, tap on the cameras Wi-Fi name “M-XXXXX” (xxxxx varies on each camera) using the default password 12345678.

  • Page 14: Basic Operations

    Once connected the background image should change from orange to the CARCAMGPS and green “Phone Connected LED” on the back of the camera will become solid. Tap on “View Camera” to display the live view. The final step is to update the current time and date by syncing them with your connected de- vice.

  • Page 15: Syncing The Time And Date

    SYNCING THE TIME AND DATE From the apps live view screen, tap on the gear icon located on the bottom right corner of the screen. Then scroll down and tap on the “Synchronize Time & Date” option. You should hear an audible confirmation from the camera and get a confirmation pop up on your phone when synced.

  • Page 16: Syncing Gesture And Impact Events

    IMPORTANT: Android users will need to disconnect from the camera (from the phones Wi-Fi settings) and repeat the sync process for the maps to come in after. TIP: The same process is used to sync Gesture and Impact events from the memory card to the App gallery.

  • Page 17: Formatting Your Memory Card

    There are several locations where you can payback recorded events, directly from the Memory card, from the App Galley and those you have saved directly to your phone. Note: Please refer to the CARCAMGPS App section for details on how to transfer events from the memory card to the App gallery.
  • Page 18 Once synced, you can tap on either the Photos (default screen) or Videos tab to view/playback the categorized content. To make it easier to find and playback video events, each event is marked by its event type: • Normal (blue): Events that are manually transferred from the Memory card to the App gallery. •...

  • Page 19: Carcamgps App

    • Due to cell phone hardware limitations, Android users may not be able use other apps or sync maps and GPS data while connected to the camera. • The CARCAMGPS App is divided up into 2 sections:...

  • Page 20: App Section

    App when needed for later playback. APP SECTION The App section of the CARCAMGPS app has an easy to use App toolbar which is divided into 4 tabs. • Camera (default screen) – Used to connect to your CARCAMGPS dash cam.
  • Page 21 FIRST TIME USERS (HOW TO CONNECT TUTORIAL) The “First time users” option provides you with a quick step by step tutorial on how to connect to the camera for the first time. To view the tutorial simply tap on the “Tap here for instructions text”, read the steps and tap on the back arrow when done.
  • Page 22 To view a travel event, use your finger to scroll through the log and tap on the event you wish to view. On the detailed event screen you can see thumbnails and location of all hand gestured events along with detailed travel information. Note: Due to hardware limitations, hand gestured thumbnails are not visible on Android devices.
  • Page 23 GALERY TAB The gallery tab is divided into two sections Photos and Videos. • Photos – Hand gestured snapshots. • Videos – Hand gestured video, Impact videos and videos that are manually transferred over from the SD card. Note: Don’t forget to connect to the camera and sync your events to keep the App Gallery updated.
  • Page 24 VIDEOS The videos section of the gallery tab stores all video events that have been synced over from the memory card (hand gestured video, G-sensor and normal). To view video events, simply swipe down on the photo screen to sync your events and tap on any of the image thumbnails to play it back.

  • Page 25: Info Tab

    The Q&A section of the info tab can be used to answer some of the most common questions you may come across when using the CARCAMGPS and is broken up into 6 categories. To view a category simply tap on any of the corresponding icons.

  • Page 26: Camera Section

    CAMERA SECTION The Camera section of the CARCAMGPS app is used to view the camera’s live view, transfer events stored on the SD card, and change camera settings. To access the camera section, con- nect make sure you are connected to your cameras Wi-Fi signal and tap on the “View Camera”...
  • Page 27 ORIENTATION The Orientation icon on the live view screen is used to switch the live view from vertical to horizontal. To do so, simply tap on the orientation icon to switch as needed. PLAYBACK The Playback icon on the live view screen is used to playback all normal recorded events that are stored on the memory card.
  • Page 28 The Memory card event gallery is divided up into 3 sections, Normal, Gesture and G-Sensor. • Normal – Collection of all recorded events • Gesture – Hand gestured events • G-Sensor – Impact triggered events Note: For the most part the Gesture and G-Sensor section of the memory card gallery will be empty since they are automatically synced over to the App gallery.
  • Page 29 SETTINGS The Settings icon on the live view screen is used to access the cameras settings page where you can make changes and adjustments to your cameras features such as syncing time & date, enabling voice prompts, etc. The settings page is simple to navigate through and consists of the following: •...

  • Page 30: Ssid

    SSID The SSID section of the settings screen displays the cameras SSID (Wi-Fi name) and Mac address. To view the Mac address simply tap on the SSID name. AUDIBLE ALERTS The Audible Alerts option is used to enable (on) or disable (off) the audible alerts that can be heard during the operation and use of the camera.
  • Page 31 When enabled, you will be prompted to enter the 4 digit security code provided by the camera. Simply tap on “Play code” when prompted, enter the code and tap on “Connect to camera”. VIDEO WITH SNAPSHOT The Video With Snapshot option is used to enable (on/default) or disable (off) the camera to save a 25 second video clip with every hand gestured snapshot.
  • Page 32 AUDIO RECORDING The Audio Recording is used to enable (on/default) or disable (off) the camera from recording audio. To make changes to this feature, simply tap on on/off switch located at the end of option. GESTURE SNAPSHOTS The Gesture Snapshots option is used to enable (on) or disable (off) the hand gesture feature and adjust the sensitivity level.
  • Page 33 G-SENSOR SENSITIVITY The G-Sensor Sensitivity option is used to change the sensitivity level of the cameras built in im- pact sensor. To make changes to this feature, simply tap on G-sensor sensitivity. The available options are: • High • Med (default) •...
  • Page 34 • Format – Erases all data on the memory card. VERSION The Version option displays the current and latest firmware version for the CARCAMGPS. To view the version information, simply tap on version to bring up the information. Storage man- agement options include: •...
  • Page 35 DISCONNECT FROM CAMERA The Disconnect from Camera option is used to quickly disconnect your phone from the CAR- CAMGPS. To disconnect from the camera, simply tap on the Disconnect from camera option. Note: This option disconnects from the app and not from the cameras Wi-Fi (SSID).
  • Page 36 LIVE VIEW PLAYBACK App Download The SecurityMan SM CARCAMGPS app can be found on both IOS and Android platforms by simply scanning the corresponding QR code below or searching for it in the Apple App-Store or Google Play- Store. IPHONE...
  • Page 37 Micro USB2.0 Microphone Yes (8KHz, 2-ch, acc) Speaker Language English/Chinese Power Requirements Input: DC12~24V, Output: DC 5V, 3.10A (2.4A for CARCAMGPS, 1.0A) Operating Temperature 4°F~140°F (-20°C to 60°C) Non-Operating Temperature 4°F~158°F (-20°C to 70°C) Operating Humidity ≤85% RH Camera Size (LxWxH) 1.50”...
  • Page 38 www.securitymaninc.com...
