Constellation Keypad Product Manual

Keypad

Button Functionality

Home - Press this button followed by your pin code to Disarm your hub
Away - Press this button followed by your pin code to Arm your hub
Stay - Press this button followed by your pin code to engage Stay your hub
Panic shield buttons - When pressed both buttons simultaneously, it will engage panic mode

Inserting and replacing the battery

Remove the battery cover and the mounting bracket
(if installed) by sliding it downward
Remove the Pull Tab to activate the CR123A
batteries as shown
The network icon on the bottom left will start blinking, indicating that the keypad is ready to join the network.
The keypad will automatically be detected, the network icon will turn OFF
Note: When the keypad is not joined to a network, the network icon will flash. Once it is joined, the network
icon will become solid anytime the keypad is awake
Constellation Connect Support | 1.888.918.7128 | support@constellationconnect.com |
B
C
D
E
For additional information, please contact us
constellationconnect.com/contact
A
A. Home
B. Away
C. Stay
D. Panic shield buttons
E. Network Icon
1
Product Guide
