Signaltec TPS II Installation Manual

Single channel current transducer system
Hide thumbs Also See for TPS II:

Advertisement

Quick Links

TPS II
Single Channel Current Transducer System
Installation Manual
MA TPS II, Ver. 1.3
1
11/2018
SIGNALTEC GmbH, Reutersbrunnenstrasse 27, D-90429 Nürnberg, GERMANY, T. +49 911 2550993-0, F. +49 911 2550993-13, Email: info@signaltec.com, Web: www.signaltec.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPS II and is the answer not in the manual?

Questions and answers

Summary of Contents for Signaltec TPS II

  • Page 1 TPS II Single Channel Current Transducer System Installation Manual MA TPS II, Ver. 1.3 11/2018 SIGNALTEC GmbH, Reutersbrunnenstrasse 27, D-90429 Nürnberg, GERMANY, T. +49 911 2550993-0, F. +49 911 2550993-13, Email: info@signaltec.com, Web: www.signaltec.com...
  • Page 2: Table Of Contents

    7.4.1. Passive plug-on burden resistor specifications 7.4.2. Active plug-on voltage amplifier specifications Switching off and deinstallation Accessories MA TPS II, Ver. 1.3 11/2018 SIGNALTEC GmbH, Reutersbrunnenstrasse 27, D-90429 Nürnberg, GERMANY, T. +49 911 2550993-0, F. +49 911 2550993-13, Email: info@signaltec.com, Web: www.signaltec.com...
  • Page 3: Receiving Of Goods

    A status-readout cable and different current and voltage output cables are available as options too. Please compare your order papers with our packing list and the received goods. MA TPS II, Ver. 1.3 11/2018 SIGNALTEC GmbH, Reutersbrunnenstrasse 27, D-90429 Nürnberg, GERMANY, T. +49 911 2550993-0, F. +49 911 2550993-13, Email: info@signaltec.com, Web: www.signaltec.com...
  • Page 4: Hardware Installation

    For this purpose, passive plug-on burden resistors and active plug-on output voltage amplifiers are available. MA TPS II, Ver. 1.3 11/2018 SIGNALTEC GmbH, Reutersbrunnenstrasse 27, D-90429 Nürnberg, GERMANY, T. +49 911 2550993-0, F. +49 911 2550993-13, Email: info@signaltec.com, Web: www.signaltec.com...
  • Page 5: Operating Instructions

    Transducer overloaded or interruption in output current loop, switch primary current off! Example: Transducer powered but overloaded, damaged or current output loop open. MA TPS II, Ver. 1.3 11/2018 SIGNALTEC GmbH, Reutersbrunnenstrasse 27, D-90429 Nürnberg, GERMANY, T. +49 911 2550993-0, F. +49 911 2550993-13, Email: info@signaltec.com, Web: www.signaltec.com...
  • Page 6: Scaling

    495 A MCTS/VM0.4/0.02 700A/7V 10.000 mV/A IT 1000-S/SP1 1000 A 707 A MCTS/VM1/0.02 1000A/7V 7.000 mV/A MA TPS II, Ver. 1.3 11/2018 SIGNALTEC GmbH, Reutersbrunnenstrasse 27, D-90429 Nürnberg, GERMANY, T. +49 911 2550993-0, F. +49 911 2550993-13, Email: info@signaltec.com, Web: www.signaltec.com...
  • Page 7: Status Readout Interface

    14 - 1 green - white * Status-Readout-Interface cable TPS/ROC is available as an option MA TPS II, Ver. 1.3 11/2018 SIGNALTEC GmbH, Reutersbrunnenstrasse 27, D-90429 Nürnberg, GERMANY, T. +49 911 2550993-0, F. +49 911 2550993-13, Email: info@signaltec.com, Web: www.signaltec.com...
  • Page 8: Specifications

    The maximum power consumption of the largest transducer IN 2000-A is around 30 W. MA TPS II, Ver. 1.3 11/2018 SIGNALTEC GmbH, Reutersbrunnenstrasse 27, D-90429 Nürnberg, GERMANY, T. +49 911 2550993-0, F. +49 911 2550993-13, Email: info@signaltec.com, Web: www.signaltec.com...
  • Page 9: Transducer Specifications

    IT 400-S IT 700-S IT 1000-S/SP1 Specifications * Verified with 50 Arms, DC … 10 kHz MA TPS II, Ver. 1.3 11/2018 SIGNALTEC GmbH, Reutersbrunnenstrasse 27, D-90429 Nürnberg, GERMANY, T. +49 911 2550993-0, F. +49 911 2550993-13, Email: info@signaltec.com, Web: www.signaltec.com...
  • Page 10: Connection Cable Specifications

    MCTS/TPS/15/0.75 loop resistance: 1.42 Ω → Maximum allowed burden resistor = 4 Ω - 1.42 Ω = 2.58 Ω MA TPS II, Ver. 1.3 11/2018 SIGNALTEC GmbH, Reutersbrunnenstrasse 27, D-90429 Nürnberg, GERMANY, T. +49 911 2550993-0, F. +49 911 2550993-13, Email: info@signaltec.com, Web: www.signaltec.com...
  • Page 11: Burden Module Specifications

    Mechanical Data Width: 51 mm Height: 51 mm Depth: 62 mm (Connectors included) Mass: 85 g MA TPS II, Ver. 1.3 11/2018 SIGNALTEC GmbH, Reutersbrunnenstrasse 27, D-90429 Nürnberg, GERMANY, T. +49 911 2550993-0, F. +49 911 2550993-13, Email: info@signaltec.com, Web: www.signaltec.com...
  • Page 12: Active Plug-On Voltage Amplifier Specifications

    Mechanical Data Width: 51 mm Height: 51 mm Depth: 62 mm (Connectors included) Mass: 105 g MA TPS II, Ver. 1.3 11/2018 SIGNALTEC GmbH, Reutersbrunnenstrasse 27, D-90429 Nürnberg, GERMANY, T. +49 911 2550993-0, F. +49 911 2550993-13, Email: info@signaltec.com, Web: www.signaltec.com...
  • Page 13: Switching Off And Deinstallation

    An unpowered transducer can be damaged. MA TPS II, Ver. 1.3 11/2018 SIGNALTEC GmbH, Reutersbrunnenstrasse 27, D-90429 Nürnberg, GERMANY, T. +49 911 2550993-0, F. +49 911 2550993-13, Email: info@signaltec.com, Web: www.signaltec.com...
  • Page 14: Accessories

    BNC to 4 mm banana-plug test lead, length 1 m length 3 m BNC4A BNC to 4 mm banana-plug adapter MA TPS II, Ver. 1.3 11/2018 SIGNALTEC GmbH, Reutersbrunnenstrasse 27, D-90429 Nürnberg, GERMANY, T. +49 911 2550993-0, F. +49 911 2550993-13, Email: info@signaltec.com, Web: www.signaltec.com...
