GM Data Interface
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake,
reverse, and speed sense)
• Retains chimes through an onboard speaker
• Pre-wired ASWC-1 harness (ASWC-1 sold
separately)
• AX-GMCL2 interface • AX-GMCL2 harness
Installation instructions for part AX-GMCL2
AX-GMCL2
2000-2013
INTERFACE FEATURES
• Designed for non-amplified models, analog
amplified models, or when bypassing a
factory amplifier
• Retains balance and fade
• Micro "B" USB updatable
INTERFACE COMPONENTS
See application list inside cover
®
Table of Contents
Connections To Be Made ................................................... 2
Installing the AX-GMCL2 .................................................. 3
Initializing the AX-GMCL2 ................................................ 3
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell caps, etc.)
CAUTION!
All accessories, switches, climate controls panels, and
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
Advertisement
Table of Contents
Summary of Contents for Axxess AX-GMCL2
- Page 1 • Retains chimes through an onboard speaker • Pre-wired ASWC-1 harness (ASWC-1 sold separately) INTERFACE COMPONENTS • AX-GMCL2 interface • AX-GMCL2 harness CAUTION! All accessories, switches, climate controls panels, and APPLICATIONS especially air bag indicator lights must be connected before cycling the ignition.
- Page 2 RPO code UQA. If UQA is present, then the vehicle is equipped with a digital amplifier. Either use the AX-GMCL2-SWC interface, or bypass the amplifier. The following (3) wires are only for multimedia/navigation radios that require these wires.
- Page 3 If the ASWC-1 is not being used, disregard this harness. If it will be used, please refer to the ASWC-1 instructions for radio • Connect the AX-GMCL2 harness into the interface, and then to the wiring connections and programming.
