Aries 2500201 Installation Manual

INSTALLATION MANUAL

Parts List

1 Driver-side fender flare
1 Passenger-side fender flare
16 Hex bolt, M6 x 20mm
16 Rivnut, M6
17 Flat washer, M6
16 Lock washer, M6
1 Insert tool, M6
1 Left hand nut, M8
1 Metal spacer

Tools Required

Ratchet Socket, 10mm
Wrench, 13mm Socket, 13mm
Drill Cut-off tool
Plier-style thread Drill bit,
set tool, M6 25/64" OR 10mm
Paint marker Trim removal tool

Torque Specifications

M6 bolt 3 ft.-lbs.
M8 bolt 7 ft.-lbs.
M10 bolt 16 ft.-lbs.
M12 bolt 28 ft.-lbs.
1/4" bolt 3 ft.-lbs.
5/16" bolt 7 ft.-lbs.
3/8" bolt 16 ft.-lbs.
7/16" bolt 20 ft.-lbs.
1/2" bolt 28 ft.-lbs.
Use above torque setting
unless otherwise noted

Level of Difficulty

Moderate
Product Image
Notes and Maintenance
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
To protect the product, wax after installing. Regular waxing is recommended
to add a protective layer over the finish. Do not use any type of polish or wax
that may contain abrasives that could damage the finish.
For polished, gloss and other smooth finishes,
polish may be used to clear small scratches and scuffs on the finish.
Mild automotive detergent may be used to clean the product.
Do not use dish detergent, abrasive cleaners, abrasive pads,
wire brushes or other similar products that may damage the finish.
Refer to the table to the left when securing hardware during the
installation process to help prevent damage to the product or vehicle.
PAGE 1 • 2500201-INS-RF • 800.798.0813 • NEED ASSISTANCE?
2500201
Scan
for helpful
install tips
• ARIESAUTOMOTIVE.COM
