INSTALLATION MANUAL
# 3100 – Straight Adapter
# 3139
8"
Offset Adapter
–
24,000 lbs GTWR, 6,000 lbs tongue
Want to see a video of the installation?
Go to www.AndersenHitches.com/videos
Or use your SmartPhone to scan this QR Code and
it will take you to our Installation Videos on the web.
Toll Free
1-800-635-6106
andersenhitches.com
• Ranch Hitch Adapter Manual – Page 1 of 8 •
RHM-08.2015
Advertisement
Table of Contents
Related Manuals for Andersen Hitches Ranch Hitch 3100
Summary of Contents for Andersen Hitches Ranch Hitch 3100
- Page 1 SUPPORT USA JOBS Made in USA INSTALLATION MANUAL # 3100 – Straight Adapter # 3139 8" Offset Adapter – 24,000 lbs GTWR, 6,000 lbs tongue Want to see a video of the installation? Go to www.AndersenHitches.com/videos Or use your SmartPhone to scan this QR Code and it will take you to our Installation Videos on the web.
- Page 2 IMPORTANT SAFETY INFORMATION Regularly check all hardware, bolts and nuts for wear and fatigue. Make sure that they are all properly tightened and secured in place. The Ranch Hitch Adapter is NOT recommended for cushioned or moveable pin boxes, only on static pin box applications.
- Page 3 Standard Pin Box Medium-Extended Pin Box Super-Extended Pin Box May need extra support, (e.g. steel gusset) •• CALL IF UNSURE •• INSTALLATION 1. Thoroughly inspect the trailer’s pin box and frame for cracks or broken welds before installing the Ranch Hitch Adapter. Repair any problems before installation.
- Page 4 6. Locate the Ranch Hitch Adapter base and apply anti-seize grease to its inner threads. Thread it clockwise onto the seated collar, being careful not to cross-thread the base (see figure 6). Spin the base onto the collar –it should spin very easily– until the base contacts the bottom of the pin box.
- Page 5 11. Attach the remote cable bracket (the part with the T-handle on the end of the cable) and the 2 self tapping screws. Choose a location under the trailer overshot that will allow the screws to penetrate the framing of your trailer. (See Figure 12). DO NOT rely on only penetrating the trailer skin, or the cable handle will work free.
- Page 6 RANCH HITCH ADAPTER ONE YEAR LIMITED WARRANTY Andersen Manufacturing, an Idaho Corporation, having its principal place of business at 3125 N. Yellowstone Highway, Idaho Falls, Idaho 83401 (”Manufacturer”) warrants its Ranch Hitch Adapter Product (the “products”) for one year from the date of purchase as follows (Subject to the Conditions and Limitations listed herein): Limited Warranty.
-
Page 7: Warranty Registration
Installed by (select one): ( ) Self ( ) Dealer ( ) Other: ______________________ Customer Signature: _____________________________________________________ * All information must be complete and sent to Andersen Hitches to validate your warranty. • Ranch Hitch Adapter Manual – Page 7 of 8 •... - Page 8 • Ranch Hitch Adapter Manual – Page 8 of 8 •...
