Redball SPK-6 Assembly Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
SPK-6 Assembly Instructions
Broadcast Hooded Retrofit Kit - 10'
Serial Number:

Advertisement

loading
Need help?

Need help?

Do you have a question about the SPK-6 and is the answer not in the manual?

Questions and answers

Summary of Contents for Redball SPK-6

  • Page 1 SPK-6 Assembly Instructions Broadcast Hooded Retrofit Kit - 10' Serial Number:...
  • Page 2 Willmar Fabrication, LLC reserves the right to make product improvements to the equipment at any time. It shall not be obligated to make such changes to machines already in service. The owner, manager and/or operator is responsible for safe, accurate operation and maintenance of the SPK-6 Broadcast Hooded Retrofit Kit.
  • Page 3 Mounting Hoods If you will leave the Redball Broadcast Hoods on when you spray with your machine nozzles, mount the hoods rearward of the machine’s spray nozzles enough to clear the spray pattern. This is usually about 12 inches from the machine’s nozzles to the front face of the hood curtain.
  • Page 4 Hoods need to be mounted so the nozzle body tip inside the hood is the same height as the machine’s nozzle body tip. Ideal spray height is achieved when the front curtain lower edge touches your target height. The rear curtains are longer and drag on the crop to provide a seal for the management of spray drift.
  • Page 5 Move the finished hood assembly to the rear of the machine. Position the hood assembly at the distance back that you want the hoods to be from the machine’s nozzles. Review the back of the machine to find the best location to make your adapters. The hood mounting kits can be positioned at each hood joining area and positioned from side to side to find the best location for your adapter.
  • Page 6 For example: This is the center boom of a John Deere 4030/4038/4045 self-propelled sprayer. A good mounting location for the hood adapter bracket has arrows pointing to them. You could cut a piece of 2 x 2 x1/8 wall tubing and weld it to the adapter plate that was sent with the kit, and then weld the tube to the flat area where the arrow is pointing.

  • Page 7: Road Transport

    SPRAYER REDBALL-HOODED SECTION On some machines, the Redball hood section may extend wider than the booms in the transport position. It may be necessary for you to add additional hazard warning lights. Also check that the SMV sign is still visible on the machine after your hoods are mounted.
  • Page 8 NOTES...
  • Page 9 Parts & Reference Materials Assembly Retrofit Kit 10'...
  • Page 10 Item No. Qty. Part Number Description 094028 ASSY, 6 HDS, CNTR BU031-200-275-5 U-BOLT; DIA 5/16'' x 2 x 2-3/4, SQ, GR 5 NTF-031 NUT, FLANGE, 5/16'' 090200 DECAL; SERIAL NO & MODEL, ALL PRODUCTS 093759 WLDMT; INSERT, GENERIC HOOD MTG KIT 093761 WELDMT;...
  • Page 11 ® Redball Gen II Broadcast Spray-Hood Curtain Installation FORWARD INSTALL WIND CURTAIN WITH CURVATURE AS SHOWN Item No. Qty.* Part Number Description 091851 CURTAIN; REAR, BROADCAST GEN II 091852 CURTAIN; FRONT; BROADCAST GEN II BH-025-075-5 BOLT; DIA 1/4'' x 3/4'' GR 5 FE-025 WASHER, FENDER;...
  • Page 12 ® Redball Gen II Broadcast Spray-Hood End Cap Item No. Qty.* Part Number Description LN-025-NI LOCKNUT, NYLON INSERT; 1/4'', GR 5 FW-025 WASHER, FLAT; 1/4'' FE-025 WASHER, FENDER; 1/2'' BH-025-075-5 BOLT; 1/4'' X 3/4'' GR5 092009 CURTAIN; END CAPS, BROADCAST GEN II REF-WF-2014-58 Rev.
  • Page 13 ® Redball Gen II Broadcast Spray Hood Nozzle Guide For optimal spray pattern functionality, it’s recommended to follow this nozzle guide. Note: spray tip patterns cannot exceed 110° ® Compatible TeeJet Nozzles* ® XRC TeeJet ® XR TeeJet Extended Range Flat Spray Tips Extended Range Flat Spray Tips ®...
  • Page 14 NOTES...
  • Page 15 NOTES...
  • Page 16 NOTES...

  • Page 17: New Product Warranty

    NEW PRODUCT WARRANTY Willmar Fabrication, LLC warrants each new Redball® and Willmar Fabrication product to be free under normal use and service from defects in workmanship and materials for a period of one (1) year from the date of first use.
  • Page 18 To Our Valued Willmar Fabrication, LLC Customer: I would like to take this opportunity to personally thank you for your recent Willmar Fabrication, LLC purchase. In an effort to serve you better, please take a moment to warranty register your new Willmar Fab product.
