NOTICE OF RESPONSIBILITY
It is the SEA FROST/C.F. Horton & Co., Inc. intent to provide the safest, most accurate
and detailed instructions. SEA FROST/C.F. Horton & Co.,Inc. cannot be responsible for
problems or damage caused by omissions, inaccuracy or interpretation of these
instructions.
SEA FROST is a registered trademark of C.F. Horton & Co.,Inc
Aspects of the SEA FROST design are covered by
TEL (603) 868-5720
DC 5000 SYSTEM 134a
OPERATION & INSTALLATION
INSTRUCTIONS
US Patent #4,356,708
2nd Edition
134 12 volt
Copyright © 1996 by C.F. Horton & Co., Inc.
FAX (603) 868-1040
1
1-800-435-6708
www.seafrost.com
