INSTALLATION INSTRUCTIONS

WR 233 WORX INTAKE GRATE

PART NUMBER:

YAMAHA 09 FZR, FZS

IMPORTANT: READ ALL INSTRUCTIONS BEFORE PROCEEDING WITH INSTALLATION

Parts Supplied:

1 x Worx Intake Grate

1 Remove stock intake grate and wipe clean any old silicone or Loctite from hull and

threaded inserts

2. Fill threaded inserts with silicone and apply a small amount of silicone to the front mounting surface and a

generous amount of silicone to the rear mounting surface and edges of your new Worx Intake Grate

3. Fit Worx Intake Grate into position using the stock mounting bolts.

4 Wipe off excess silicone with a damp cloth. Allow 4-6 hours minimum for silicone to cure before riding.

5. Regularly check that all bolts are tight on your intake grate and ride plate.

6. Regularly check the condition of your intake grate after use.

Thank you for purchasing Worx Racing Components Products. We firmly believe that Worx Racing Components

Products are among the finest watercraft parts available.

A great deal of time and effort has gone into the design and development of this product to ensure that it will

perform to the highest standard and that installation is a relatively straight forward and simple procedure.

If you have any questions or comments on the performance and/or installation of our products, please contact us at

the above numbers.

Please note – Damage may occur to this grate if installed and used on a personal water craft that exceeds 80 mph. It

is advised that caution be taken if installing on a watercraft exceeding 80 mph. Constant and regular checks of the

condition of the grate is highly recommended for craft exceeding 80 mph. If the condition of the grate has been

compromised in any way please remove immediately. Damage or injury to the grate, personal watercraft or persons,

is the responsibility of the installer of this grate.

RIDE SAFELY PROTECT OUR ENVIROMENT

AND RESPECT OTHERS WHO SHARE OUR WATERWAYS
