- Page 1 Built-in Warming Drawer W 200SSS W 200BBS Installation and Operating Manual...
-
Page 2: Table Of Contents
CONTENTS Important Notes -------------------------------------------------------------------------------------Page 2 Installation Instructions ---------------------------------------------------------------------------Page 3 Technical Specification ----------------------------------------------------------------------------Page 4 Warming Drawer Overview ------------------------------------------------------------------------Page 4 Control Panel ----------------------------------------------------------------------------------------Page 5 Cookware Safety ------------------------------------------------------------------------------------Page 6 Cleaning and Maintenance ------------------------------------------------------------------------Page 6 Troubleshooting -------------------------------------------------------------------------------------Page 7... -
Page 3: Important Notes
Important Notes Dear Customer Thank you for choosing our product. This appliance is easy to use; however please read this handbook carefully before installing and operating it. Herein, you will find the correct method of installation and tips for best use and maintenance of the product. This appliance is designed to be handy for any adult to use at home. -
Page 4: Installation Instructions
Installation Instruction Product & cutout dimensions for WD200SSS WD200BBS Fit the appliance into its cabinetry by inserting screws into the 4 holes that can be seen in the frame of the warming drawer when the door is open. Installation Rubber 4X29 self tapping screw The warming drawer needs a supporting surface underneath. -
Page 5: Technical Specification
Voltage / Frequency 220-240Vac / 50Hz Heating Element Rated Power 500 W Ventilation Motor Rated Power 15 W Temperature Range 35-75°C (Adjustable) Model Number WD200SSS / WD200BBS Timer 120 min Max Load 20 kg Capacity 9 place settings Rater Power 515 W... -
Page 6: Control Panel
Control Panel Indicator Light Yellow to indicate warming drawer Indicator Light is in operation Green to indicate mode power on Timer Turn clockwise to set the timer from 0 to 120minutes Temperature adjustment knob ℃ Turn clockwise to set temperature Turn anticlockwise to enable warming drawer to work... -
Page 7: Cookware Safety
Cookware Safety Plastic containers or plastic wrap can melt if in direct contact with the drawer or a hot utensil. If it melts onto the drawer, it may not be removable. Do not place plastic cutleries or bottles which have a melting point below 100°C into the drawer. Use heat-safe dishes only. -
Page 8: Troubleshooting
Troubleshooting NOTE: The maintenance and service must be carried by qualified service person. Repairs and other work by unqualified persons could be dangerous. The manufacturer is not liable for any direct or indirect damage caused by unqualified service person or installer. Scenario Possible Causes Solution...
